3"
"
4) When using an instrument or replacing a part for repairing, check it is applied to
rated voltage current and capacity.
5) Prevent water from flowing into electric elements in mechanical parts.
6) When carrying or tilting the appliance, remove all the objects on it.
7) If the cooling cycle is out of order, contact nearest authorized service center for
maintenance, repair and adjustment.
1. SPECIFICATION & PARTS IDENTIFICATION
MODEL
C12E (CHILLER)
DIMENSION
410W×210D×290H(mm)
WEIGHT
12.5kg
CONSUMPTION
120W
TEMP CONTROL
AUTO
TANK
Stainless Steel
COLD
CAPACITY
5.0 /h (10)
ELECTRICAL
220-240V, 50/60Hz. 110-127V, 50/60Hz.
Check the available power supply against the watercooler data plate to assure correct electrical service.
