Clover Flex Quick Start Guide

9 Clover Flex Starter Kit Quick Start Guide
SIM Installation
Power off the device by holding the power button until you see the
power off button on the screen, then tap it.
7-8
Open the receipt paper door and
locate the screws above the serial
number (S/N).
Use the screwdriver to turn the
screws counter-clockwise 7–8
times; the screws won’t fall out.
Use your fingernail or screwdriver
to pull down black ap.
Slide the SIM card into the tray
and align it with the angled corner.
Finally, close the ap, tighten the
screws, and power on the device.
Locate the left tray and remove the
current SIM card.

Clover Flex Specifications

General

Memory	1 GB RAM
Connectivity	Wi-Fi, Bluetooth, 4G LTE
Operating System	Android
Card Reader	EMV Chip Card Reader, NFC Contactless Reader, Magnetic Stripe Reader
Storage	8GB Flash
Camera	5MP Rear-facing camera
Ports	USB-C, 3.5mm audio jack
Payment Options	Magstripe, EMV, NFC
Security	PCI PTS V5.0
Processor	Quad-core ARM Cortex-A7
