Figure no .3
3.3. Improper use of the machine.
Paddle mixer is not used for mixing frozen meat at temperature below + 2 ° C, boned
meats, hard products, flammable liquids.
3.4. Control panel
Machine control is available when voltage is applied to the switch cabinet by turning the main
switch lever from position "0" to "I".
The machine is equipped with a control panel (Fig.no. 4). There are following items on the
control panel: inward rotation button, outward rotation button, mixing shafts variable speed
potentiometer, lifting up/lowering down (in option with intergrated loading pillar), STOP
button, the green light indicator signalize operation of the machine, emergency STOP button,
on the right side.
Fig. 4. Control panel.
4
