CME WIDI JACK - WIDI Jack Cable Options; WIDI Jack LED Indicator

6 / 17
⚫ WIDI Jack Cable Options
Model
Description
25DIN5
2.5mm mini TRS Jack to
5-pin DIN male cable
25TRS35
2.5mm mini TRS Jack to
3.5mm (1/8”) TRS Jack cable
25TRS25
2.5mm mini TRS Jack to
2.5mm mini TRS Jack cable
25DIN6mini
2.5mm mini TRS Jack to
6-pin mini DIN male cable
25TRS635
2.5mm mini TRS Jack to
6.35mm (1/4”) TRS cable
⚫ WIDI Jack LED indicator
Video instruction: https://youtu.be/BvPyvlnH9sA
 When the power is supplied normally, the LED light will be lit.
 Blue LED flashes slowly: the device starts normally and waits for
connection.
