Location of controls
- 6 -
11 FUNCTION Function selector RADIO, OFF,
MP3/CD
12 -VOLUME+ Decrease volume
Increase volume
13 Speaker speaker (left & right)
14 SD JACK SD or MMC card slot
15 LCD Display
16 USB JACK Port for MP3 player / USB stick
17 Tuning Select radio function
18 AM/FM/FM ST. Switch to AM/FM/FM ST.
19 Battery compartment 8 pieces (1,5V, UM-2/C/LR14)
20 AC 230 Volt
11 12
13 14 15 16 17 18
13
19
20
