300026(B1&B2)
ITEM:
ASSEMBLY TIME
PARTS IDENTIFICATION
B1 (BOX1)
HARDWARE IDENTIFICATION
Z-B2(BOX2) - HARDWARE PACK IS LOCATED IN 300026 (B2)
NOTE :
Phillips head screw driver is required in the assembly process; However, manufacturer does not provide
this item
ASSEMBLY INSTRUCTIONS
ASSEMBLY TIPS:
WARNING!
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instruction in the same sequence as numbered to assure fast & easy assembly.
1.Don’ t attempt to repair or modify parts that are broken or defective. Please contact the store
immediately.
2.This product is for home use only and not intended for commercial establishments.
1
LONG BOLT
(1/4 x 100 x 13mm -
RBW)
SHORT BOLT
(1/4 x 32 x 13mm - RBW)
2
LONG
FLAT HEAD S
CREW
(4 x 30mm - RBW)
3
SHORT
FLAT HEAD S
CREW
(3 x 20mm - RBW)
4
WOOD PLUG
( 14.5 x 9mm-
WHT)
5
ALLEN WRENCH
(4MM - RBW)
6
16PCS
4PCS
1PC
BARREL NUT
(1/4 x 13mm -RBW)
4PCS
8PCS
12PCS
4PCS
7
30 MINUTES
4PCS
B2 (BOX2)
GN FINIAL
1PC
1PC
IN RIGHT LEG FRAME
4PCS
JN CASTER
AN FRONT RAIL
1PC
BN BACK
FRAME
1PC
CN ROLL SLAT
(13PCS)
1PC
DN TRUNDLE FRONT RAIL
1PC
EN TRUNDLE BACK RAIL
2PCS
FN TRUNDLE SIDE
PANEL
HN LEFT LEG FRAME
2SETS
