HARDWARE IDENTIFICATION
Z-B2 (BOX 2) - HARDWARE PACK IS LOCATED IN 460441 (B2)
1 LONG BOLT 32PCS 5 SHORT BOLT 16PCS
2 BARREL NUT 32PCS 6
LONG FLAT HEAD
16PCS
3 WOOD DOWEL 36PCS 7 ALLEN WRENCH 1PC
4
MEDIUM BOLT 20PCS 8
SHORT FLAT HEAD
SCREW
24PCS
NOTE:
Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item.
PAGE 3 OF 7
(1/4 x 30mm - BLK)
(1/4 x 13mm - BLK)
(10 x 40mm )
(1/4 x 35mm - BLK)
(4 x 30mm - BLK)
(3 x 10mm - BLK)
(1/4 x 90mm - BLK)
(4MM - BLK)
ITEM:460441 (B1-B4)
ASSEMBLY INSTRUCTIONS
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2.
Please check to see that all hardware and parts are present prior to start of assembly.
WARNING!
2.
This product is for home use only and not intended for commercial establishments.
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the store
immediately.
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
