ASSEMBLY INSTRUCTIONS
ASSEMBLY TIME
PARTS IDENTIFICATION
120 MINUTES
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
WARNING!
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the store immediately.
2. This product is for home use only and not intended for commercial establishments.
NOTE:
Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item.
A
LEFT SIDE
PANEL
1 PC
B
LEFT DIVIDER
PANEL
1 PC
C
RIGHT DIVIDER
PANEL
1 PC
D
RIGHT SIDE
PANEL
1 PC
E BOTTOM PANEL 1 PC
F TOP PANEL 1 PC
G
MIDDLE BACK
PANEL
1 PC
H BACK PANEL
2 PCS
I
ADJUSTABLE
SHELF
1 PC
J
LARGE
DRAWER
FRONT PANEL
2 PCS
K
LARGE
DRAWER BACK
PANEL
2 PCS
L
LARGE LEFT
DRAWER SIDE
PANEL
2 PCS
M
LARGE RIGHT
DRAWER SIDE
PANEL
2 PCS
N
DRAWER
BOTTOM PANEL
5 PCS
O
SMALL
DRAWER
FRONT PANEL
3 PCS
P
SMALL
DRAWER BACK
PANEL
3 PCS
