ASSEMBLY INSTRUCTIONS
ASSEMBLY TIME
PARTS IDENTIFICATION
90 MINUTES
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
WARNING!
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the store immediately.
2. This product is for home use only and not intended for commercial establishments.
NOTE:
Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item.
MAX TV SIZE : 65”
A
LEFT SIDE
PANEL
1 PC
B
RIGHT SIDE
PANEL
1 PC
C
LOWER DIVIDER
PANEL
1 PC
D
LOWER DIVIDER
PANEL
1 PC
E
UPPER DIVIDER
PANEL
2 PCS
F CROSS BRACE
2 PCS
G BOTTOM PANEL
1 PC
H SHELF
1 PC
I
LARGE TOP
PANEL
1 PC
J
SMALL TOP
PANEL
1 PC
K TOP GLASS
1 PC
L
ADJUSTABLE
SHELF
3 PCS
M BACK PANEL
2 PCS
N BACK PANEL
1 PC
O BACK BOARD
1 PC
P BACK BOARD
1 PC
