Coaster CONNECT IT - Hardware Identification; Hardware Identification (1-16)

PAGE 3 OF 14
NOTE:
Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item.
HARDWARE IDENTIFICATION
Z
NO DESCRIPTION FIGURE Q’TY
1 GLUE 40g 1 PC
2
LARGE WOODEN
DOWEL
Ø8x30mm
58 PCS
3
SMALL WOODEN
DOWEL
Ø6x25mm
12 PCS
4
CAM LOCK
Ø15x12mm SR
20 PCS
5
CAM BOLT
Ø7x35.5mm SR
20 PCS
6
SCREW
Ø3x10mm SR
30 PCS
7
SCREW
Ø4.5x42mm SR
4 PCS
8
SCREW
Ø4.2x35mm SR
12 PCS
NO DESCRIPTION FIGURE Q’TY
9
SCREW
Ø4x15mm SR
18 PCS
10
HANDLE
L=120mm
1 PC
11
HANDLE
L=400mm
3 PCS
12
BOLT
Ø4x23mm SR
11 PCS
13 POWER OUTLET 1 PC
14 HINGE
4 PCS
15
WIRE COVER CAP
Ø60mm
3 PCS
16
RAIL
L = 250mm WHT
DR
DL
CL
CR
3 SET
Q
LEFT DRAWER
FRONT PANEL
1 PC
R
MIDDLE
DRAWER
FRONT PANEL
1 PC
S
RIGHT DRAWER
FRONT PANEL
1 PC
T
DRAWER BACK
PANEL
2 PCS
U
DRAWER BACK
PANEL
1 PC
V
LEFT DRAWER
SIDE PANEL
3 PCS
W
RIGHT DRAWER
SIDE PANEL
3 PCS
X
DRAWER
SUPPORT
3 PCS
Y
DRAWER
BOTTOM PANEL
3 PCS
AA DOOR
1 PC
