Coats Vero Series User Manual

Important: Always read and follow instructions. • 5
A
A - Touchscreen
B
B - ON/OFF Switch (Back Of Machine)
C
C - Plug (Back Of Machine)
D
D - Weight Tray Studs
E
E - Weight Tray with Pockets for Weights
G
G - Hood (Wheel Guard)
H
H - Hood Sonar (Width Sensor), if equipped
J
J - 40 mm Shaft
K
K - Laser Locator
L
L - Offset Arm, Measures A & D of Tire/Wheel
(Shown In Home Position)
Note: Throughout this manual, wheel weights are
referred to as Clip-on or Tape-A-Weight®. Figure 4
shows an example of each weight.
Figure 4 - Corrective Weight Examples. For Best Results, use
BADA® Brand Wheel Weights.
Power Switch
The ON/OFF switch location (figure 5) is on the left
side of the balancer; below the weight tray.
Figure 5 - On/Off Switch
Weight Tray
Weight pockets are laid out so that wheel weights are
easily accessible. Use the weight tray studs for handy
storage of wheel mounting adapters.
Figure 6 - Top Down View of Weight Tray With BADA Brand
Wheel Weights and COATS® Brand Accessories
ON/OFF
Power
Switch
Clip-on Weight Tape-A-Weight
®
