Batteries
17
When mounting the charger, make sure it is placed in a dry place and
away from direct sunlight. The charger is not waterproof.
Connecting to power
The charger can be supplied from DC or from AC using an AC/DC
converter.
DC: Connect the 12-24VDC Connection Cable between the DC supply and
the connector on the underside of the charger.
AC: Connect the AC/DC converter to the connector on the underside of the
charger. Then connect the AC/DC converter to the AC outlet.
Recharging the battery
To recharge the battery, place the radio with battery or the battery alone
in the front position of the charger cradle.
If the radio cannot turn on due to complete discharged battery, then turn
of the radio and place it in the charger or charge the battery alone.
The light indicators on the charger cradle show the status as follows:
• Green light: Power is connected to the charger.
• Steady red light: Charging completed. Trickle charge mode.
Charging time with empty battery: UHF off
approx. 4 hours, UHF on: approx. 5 hours.
The battery indicator on the radio display
indicates if the radio is placed in the
charger while radio and charger are both
powered.
1711
