Technical specifications
28
Transmitter
Receiver
Item Specification
RF output power 2 W /1 W
RF output power, Canada 2.5 W ±1 dB / 0.75 W ±1 dB
Max deviation ±5 kHz
Spurious emission < 0.25 uW
Adjacent channel power > 70 dB
Item Specification
Sensitivity (20 dB SINAD) -117 dBm typical
Intermodulation Better than 70 dB
Spurious response > 70 dB
Adjacent channel selectivity > 70 dB
Audio output, internal 0.25 W at 10% dist.
Audio output, external 0.25 W/8 ohm
