Console/Head Access
Located at the top on the inside of the console/head
access door is a locking gas shock that aides in opening
the door and keeping the door open once the shock is
fully extended. With the door fully opened, it can only
be closed by releasing the pressure of the metal sleeve
on the door side against the shock that is mounted to
the console. To do this, open the door to its fullest open
position, thereby allowing the door slide sleeve to be
moved so that it will slide overtop of the gas shock as the door closes. Failure to release
this locking mechanism while attempting to close the door will lead to the gas shock
failing, or damage to the mounting brackets.
Electric Head
The macerator is to be used only with direct discharge thru hull. The macerator will not
be used for dockside pump out of the holding tank. To flush the head, make sure intake
valve is in the open position, supplying your head with the water it will need to operate
correctly. Then press the toilet switch and the waste is pushed into the holding tank. The
intake and discharge valves are located in the fwd bilge access area under the sink. The
macerator has nothing to do with the flushing of the toilet as it is only used for
overboard discharge while outside the legal dumping limits. To discharge outside legal
limits, open the thru hull discharge valve located behind the intake valve, turn the Y-
Valve so the arrow towards the macerator is exposed, and flip macerator switch to the
“ON” position. The Y-Valve and macerator pump are also located in the fwd. bilge access
area.
