Trim tabs allow for maximum boat performance
and are great for balancing weight in the boat.
They also allow the boat operator to lift or lower
the hull to accommodate for different running
situations.
For the operation of trim tabs note that the port
trim tab switch will affect the port side of the boat,
and the starboard switch will affect the starboard
side. To lower a particular side, press the top of
the corresponding switch down. Pressing the top
of both switches down will lower the bow evenly.
To raise the bow; press the bottom of the corresponding switch.
Pull Up Bow Light and Cleats
The bow light and cleats are stainless steel pull up style and can remain hidden when
not in use. This is especially helpful while fishing as it leaves nothing in the bow to
interfere with your line. The bow light lifts from the indent at its front. It will lock in
place once fully pulled up.
To raise the cleats simply grip the indents and lift until locked. To recess these items
simply push them back into the deck. As with all stainless moving parts on your Cobia, it
is recommended that you routinely apply a stainless safe corrosion inhibitor and
lubricant to keep these items working properly.
Cockpit Courtesy Lights
The cockpit comes equipped with seven lights: four installed beneath the port and
starboard gunwale boards, two under each gunwale board, one at the forward bow
bulkhead underneath bow filler, two on the forward starboard and port bulkhead. The
cockpit lights are operated by the sixth switch from the left on the console switch panel.
The courtesy lights are operated by the fourth switch and are located on the outboard
sides of the console and the steps leading into the head unit.
