• Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
• Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool
or these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
• Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
• Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
• Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different than those intended could result in a
hazardous situation.
Service
• Have your power tool serviced by a quali ed repair
person using only identical replacement parts. This will
ensure that the safety of the power tool is maintained.
This machine has manual cable feed. The cable must be
fed by hand and does not automatically extend or retract
into the machine.
This machine should not be operated in reverse under
normal operating conditions. Reverse should be used only
for a few seconds at a time to free a stuck cutting tool.
1. Belt Guard
2. Belt
3. Extension Spring
4. Cable Drum
5. Wheels (2)
6. Foot Switch Actuator
7. Motor (115v/ 60HZ)
8. Base Frame
9. GFCI (Ground Fault Circuit Interrupter)
10. Uprights (2)
11. Frame release pin
12. Telescoping Handle
MACHINE DESCRIPTION
Tool description
Your cable drum machine has four bene cial tool
attachments to cope with a wide variety of obstructions.
As a general guideline, it is wise to use a tool that is at
least 1' smaller than the line to be cleared. The nature of
the job and the operator’s judgment should determine the
type of tool.
• ST-96205
• 3/4" x 5"
Straight Boring Head
for initial exploration of clog
• ST-96207
• 1-1/2" x 2"
Slotted Spear Head
for piercing clogs
• ST-96201
• 1-1/4" x 2"
Grease Cutter
for grease blockages
• ST-96205
• 2" x 4"
Side Cutter
for nishing pipe cleaning
4
7
5
3
1
6
8
2
10
12
11
9
