Page #9 background imageLoading...
Page #9 background image
1N4004
3 A
NERO BLACK
NERO BLACK
OK
PASS
TX
LED
RX
Filo BIANCO WHITE wire J17
Filo BIANCO WHITE wire J17
Filo BIANCO WHITE wire J17
E
C
D
F
ROSSO
RED
(TX)
RX
TX
RX
TX
Antenna
Collegamenti sensori U.S.,
pannellino-LED e antenna.
U.S. sensors, LED panel
and antenna connections.
B
Installare ponticello (vedi catalogo) fra TX
ed RX Ultrasuoni, se non viene utilizzato il
sensore volumetrico.
Install the jumper wire (see the catalogue)
between the U.S. TX and RX, if you don't use
the volumetric sensor.
A
-
-
BIANCO
WHITE
(RX)
Collegamento dell'avvisatore acustico del veicolo
con relè supplementare.
Vehicle horn connection with additional relay.
87
30
86
85
Impianto
originale
Original
system
Relè
supplementare
Additional
Relay
Relè originale comandato da un segnale negativo.
Collegamento dell'avvisatore acustico con segnali
di controllo negativo applicato al relè originale.
Original relay controlled by a negative signal.
Vehicle horn connection with negative control signal
to the original relay.
87
30
86
85
Y
PASS
TX
LED
RX
Y
1
2
3
U.S.
U.S.
+30
+
-
15 A
+30
- / +
- / +
