Cobra 4693 - Page 8

COLLEGAMENTI SIRENA NO WIRELESS (5362)
NO WIRELESS SIREN CONNECTIONS (5362)
COLLEGAMENTI SIRENA WIRELESS (5365)
WIRELESS SIREN CONNECTIONS (5365)
PULSANTE COFANO
BONNET PUSH-BUTTON
PANNELLINO LED
LED PANEL
J-21
Vedi scheda
tecnica vettura
See the car fitting
instructions
J-8
Vedi scheda
tecnica vettura
See the car fitting
instructions
3 A
+30
1
2
LED
Ø 10 mm
1
2
1
2
3 A
ROSSO RED
NERO BLACK
+30
BLU BLUE
NERO BLACK
GIALLO-BLU YELLOW-BLUE
1
14 mm
Ø 10 mm
Ø 2 mm
2
Ø 10 mm
J
G
Antenna
GIALLO-BLU YELLOW-BLUE
NERO BLACK
ROSSO RED
NERO BLACK
BLU BLUE
