Cobra Fortis 14L - Page 11

11
FIG. 5
FIG. 6
Fitting the throttle cable:
Follow the steps below to install the throttle control cable to the engine.
1. Remove the air filter cover (Fig. 5)
2. Remove the air filter (Fig. 6)
3. Remove 2 screws from the air filter base. Refer to red circles in Fig. 7
4. Remove air filter base. Refer to Fig. 8
Fig. 5 Fig. 6
Fig. 7 Fig. 8
