Cobra HH 38 WX ST User Manual

Turn clockwise.
1
⁄4 turn.
Operation
Operation
Attach Antenna
32
Scan
Func
CH9/19
DW
Lock
CB/WX
Pwr Saver
PWR SAVE WX
SCAN DW EMG
FUNC
40
SIGNAL
POWER
Attach Antenna
Insert.
1
2
Remove battery chamber cover. Press down on
arrow and slide.
Install batteries by polarity markings.
Replace cover.
Battery
Installation
Attach Belt Clip
Install Batteries
1
2
3
Note
Ignoring polarity markings (+/-)
can cause damage to both the
unit and the batteries.
The HH 38 WX ST requires
9 “AA” alkaline or NiCD
batteries (not included with
the unit).
When batteries are low or need
charging the BATTERY icon
will flash on the LCD display.
Replace alkaline batteries or
recharge NiCD batteries.
NiCD rechargeable batteries
should be charged a minimum of
12 hours with a CA-45C charger.
NiCD rechargeables should have
a rating of 1.2 vdc, 750 Mah.
Note
Clip slides up to attach and
slides down to remove.
To remove belt clip,
lift tab out and slide
belt clip down.
1
2
Attach Belt Clip
Slide belt clip up on
rails of base until
tab locks.
Press and
hold down
on arrow
and slide
NiCD rechargeable batteries
should be charged a minimum
of 12 hours with a CA-45C
charger.
Note
To increase range as a
portable, use CA41 telescopic
loaded long range antenna.
(See Accessory Page 35).

Cobra HH 38 WX ST Specifications

General

Maximum range	6439 m

Weight and Dimensions

Dimensions (WxDxH)	521 x 44 x 171 mm
