Cobra HH 50 WX ST User Manual

HH
50 WX ST Specifications
33
GENERAL
CHANNELS . . . . . . . . . . . . . . . . . . . CB - 40 CH
WEATHER - 10 CH
FREQUENCY RANGE .......... CB - 26.965 TO 27.405 MHZ
WEATHER - 161.650 TO 163.275 MHZ
FREQUENCY TOLERANCE ..... 0.005 %
FREQUENCY CONTROL ....... PLL (PHASE LOCK LOOP) SYNTHESIZER
OPERATING TEMPERATURE
RANGE . . . . . . . . . . . . . . . . . . . . . . . -30° C TO + 50° C
MICROPHONE . . . . . . . . . . . . . . . . ELECTRET, P
USH-TO-TALK
INPUT VOLTAGE ............. 13.5 VDC (INTERNAL 9AA BATTERIES)
13.8 VDC, EXTERNAL
ANTENNA CONNECTOR....... BNC
METER ....................... LCD DISPLAY, ICONS
WEIGHT...................... 10.02 oz. without batteries
15.09 oz. with batteries
TRANSMITTER
POWER OUTPUT.............. 4.0 W AT 13.8 VDC - HIGH, 1.0W - LOW
MODULATION................ AM
FREQUENCY RESPONSE....... 300 - 3000 HZ AT -6 dB
OUTPUT IMPED
ANCE ......... 50 OHMS, UNBALANCED
RECEIVER
CB
SENSITIVITY ...................LESS THAN 1 uV FOR 10 dB S/N
IF .............................DUAL CONVERSION SUPERHETERODYNE
AUDIO OUTPUT ...............400 mW MAXIMUM AT 10% DISTORTION
FREQUENCY RESPONSE....... 300 - 3000 HZ AT -6 dB
2ND IF IMAGE REJECTION..... GREATER THAN 60 dB
ADJACENT CH. REJECTION.... 50 DB MIN.
AUTOMATIC NOISE LIMITER... BUILT- IN
FREQUENCY CONTROL ....... PLL (PHASE LO
CK LOOP)
WEATHER
SENSITIVITY .................. LESS THAN 1 uV FOR 12 dB SINAD
IF FREQUENCY................ DUAL CONVERSION
SUPERHETERODYNE
AUDIO OUTPUT ...............MAXIMUM 400 mW AT 10% DISTORTION
FREQUENCY RESPONSE....... 300 - 3000 HZ AT -6 dB
