9
5. ASSEMBLY
WARNING: Switch off and remove the battery from machine before adjusting or cleaning. The blades
continue to move for a fraction of a second after the hedge trimmer is switched off. Do not touch the moving
blades.
5.1 ATTACHING THE HEDGE TRIMMER
The battery should be removed before proceeding:
Insert the hedge trimmer attachment into the main
shaft of the tool. Align the arrows on each shaft.
The electrical connectors within the shafts will
locate.
Tighten the collar of the main unit, locking the two
shafts together.
5.2 ADJUSTING THE LENGTH
Rotate the collar indicated opposite
counter-clockwise to loosen the lock on the shaft.
Adjust the length as required, then secure in
position by rotating the collar clockwise.
Do not extend the length such that the handle will
be above waist height.
Make sure the shaft is locked in place and safe
to use before proceeding.
