3. PARTS DESCRIPTION
Fig.1B
1. Upper handle 2. Brake control handle 3. Throttle choke lever
4. Starter handle 5. Rope Guide 6.Locking lever
7. Grass catcher 8.Lower handle 9. Height adjusting lever
10. Deck 11. Sideward flap 12. Spark plug
10. Oil cap 14.Fuel cap 15. Cable clamp
16. Height adjusting lever 17. Self-drive control handle 18. Side discharge channel
19. Mulching wedge
Including
A: Spark plug wrench
4. TECHNICAL DATA
Model
MX564SPB
Engine type
126T
Self-propelled
Yes
Engine displacement
190 cm
3
Blade width
560mm
Rated speed
2800/min
Fuel tank capacity
1.0L
Grass catcher capacity
70L
Net Weight
39.8kg
Height adjustment:
25~75mm,7 adjustment
