Cobra RM46B User Manual

- 7 -
4. TECHNICAL DATA
Model
RM46SPB
RM46B
RM46C
RM46SPC
Engine type
Briggs 500E
Briggs 500E
DG450
DG450
Self-Propelled
Yes
No
No
Yes
Engine Displacement
140cm³
140cm³
135cm³
135cm³
Blade Width
460mm
460mm
460mm
460mm
Rated Speed
2800/min
2800/min
2800/min
2800/min
Fuel Tank Capacity
0.8L
0.8L
1.2L
1.2L
Grass catcher capacity
55L
55L
55L
55L
Net Weight
31.9kg
29.9kg
34.4kg
36.7 kg
Height adjustment:
17~75mm, 6 adjustment
RM46SPB
RM46B
RM46C
RM46SPC
Guaranteed Sound pressure level
at operator’s position
(According to EN 836 Annex H &
EN ISO 4871)
84,3dB (A)
(k=3 dB (A))
84,3dB (A)
(k=3 dB (A))
86,0dB (A)
(k=3 dB (A))
86,0dB (A)
(k=3 dB (A))
Measured sound power level
Guaranteed Sound Power level
(According to 2000/14/EC)
94,0dB (A)
k= 2,25dB (A)
96dB(A)
94,0dB (A)
k= 2,25dB (A)
96dB(A)
91,7dB (A)
k= 1,81dB (A)
96dB(A)
91,7dB (A)
k= 1,81dB (A)
96dB(A)
Vibration
(According to EN 836 Annex G)
6,432m/s²
k=1,5 m/s²
6,432m/s²
k=1,5 m/s²
2.988m/s²
k=1,5 m/s²
2.988m/s²
k=1,5 m/s²
5. ASSEMBLY
5.1 FOLDING HANDLE
1. Fix the lower handlebars onto the mower body with bolts, washers with a suitable spanner. (Fig. 1A/Fig.1B)
2. Release the upper handlebars for folding.
3. Push the locking lever closed to lock the handlebars in the operating position. (Fig.1C/Fig.1D)
4. Adjust the tension by turning the lock nut with a suitable spanner. (Fig.1C)
5. Attach the cable-clamp to the position shown and then attach the cable. (Fig.1E)
Fig.1A Fig.1B Fig.1C
