7. Scarifier Operation
It is recommended to start scarification/aeration at a point close to the power supply and
to work your way away from the supply. Proceed at a right angle from the power supply
and place the power cable to the side which has already been scarified (E).
Warning ：When scarifying do
not allow the motor to labour
particularly in heavy conditions.
When the motor labours the speed of the
motor drops and you will hear a change in
the motor sound, when this occurs stop
scarifying, release the switch lever and raise
the height of cut. Failure to do so could
damage the machine.
NOTE: the motor is protected by a safety cut
out which is activated when the blade
becomes jammed or if the motor is
overloaded.
Safety Overload:
When this occurs, stop the machine and
remove the plug from the power supply. The safety cut out will only reset when the switch
lever (10) is released. Clear any obstruction and wait for a few minutes for the safety cut
out to reset before continuing to operate. At this time do not operate the switch lever (10)
as this will prolong the reset time of the safety cut out. If the tool cuts out again, increase
the height of cut to reduce the load on the motor.
8.Technical Data
Electric Lawn Rake LS-S4001A
Rated power 1800W
Blade length 40cm
Height of cut +8 to -12mm
Collector capacity 40L
Net weight 12kg
Protection class
/IPX4
Working speed of the aerator cylinder 3900～4300rpm
Sound power level 102dB(A)
E
