Remote Control
7
7
Remote Control
Preparation of Remote Control
Take the back cover off of the remote control and insert supplied coin battery and put on the
cover. (Refer pg6 for detail)
Using Remote Control
Point the remote to the sensor by about 60 degrees of no more than 7 meters
The operating distance may vary depending to the brightness around.
Notes:
a) Do not point bright lights directly at the remote control sensor.
b) Do not place objects between the remote control unit and the remote control sensor.
c) Do not use this remote control unit while simultaneously operating the remote
control unit of any other equipment.
Power Connections
8
Connect to AC adaptor
**Do not connect the power cord until all other connections have been made.
Power is supplied through the provided appropriative power adapter, one end of which is
connected to the DC IN jack on the main unit, another to wall outlet with AC100-240V.
Note:
a. If you have difficulty inserting the plug, turn it over and reinsert it.
b. If the unit will not be in use for long periods of time, disconnect the plug from the outlet.
c. In order to prolong the operation life, the intervals of continuous power on should be not less
than 30s.
AC adapter:
This AC adapter operates on
100-240V~~50/60Hz 2A Min
DC OUT: 12V/2A
AC100-240V
１
２ ３
４
５
６
７
８
９
０
TV/AV MENU
Volume
Channel
CALL
RE
CALL
TF-TV505
To DC in jack
To Next Page
