Coby TFTV1925 User Manual

7
Coaxial Output - Digital Audio Output Connector
WhenMPEG audioorDolby Digitalaudio isplayed, DolbyDigital bitstream orMPEG audiobitstream is
senttotheplayer’sdigitalaudiooutputconnector.WhentheplayerisconnectedtoaDolbyorMPEGaudio
decorderviathisoutputsocket,youcanenjoytheater-qualityaudioinyourhome.Anopticalaudiocableis
requiredwhenaDolbyDigitaldecoderorMPEGaudiodecoderisused.Thementionedcableisnotincluded
withthisproduct.
External Audio and Video Signal Input - HDMI, RCA, S-VIDEO,COMPONENT.
Theplayer'sAVfunctionwouldenableuserstoviewprogramsfromexternalsignalsources.
Fourinputmodesareavailableforyoutochosefrom,itranksasbelowinregardtoimagedenition:HDMI/
COMPONENT/S-VIDEO/RCA
Cable Connections
Amplifier equipped with a
DolbyPro Logic Surround
Coaxial Cable
IMPORTANT NOTICE - When work with external device,
Be sure to have all necessary connections properlydone beforeconnect the•
powersupply.
Settheunitintotherelativeinput/outputmodetoenablethesignalpass.•
Refertothemanualofexternalsourcesaswell.•
NOTE:
WesupplyonesetofAVcableandonepieceofpowercordwiththisproduct.
The white/red plug of theAVcableisforthe audio L/Rconnection andtheyellow
plugforthevideoconnection.Thewhite/red plugoftheAVcablecanalsobe used
separatelytoinputtheaudiosignalintheS-video/Componentconnection.
Therestofcableneededforotherneccessaryconnectionsarenotincludedwiththis
product,pleasecheckwithelectronicstore.
