Coby TFTV1925 - Connecting Cables

9
S-Video Input
TheS-Videoportiscapableofacceptingsignalsfromstandardvideosources.(e.g.,cable/satelliteboxes,
DVDplayers,VCRs,etc.)
RCA Input
TheCVBSportiscapableofacceptingsignalsfromstandardvideosources(e.g.,cable/satelliteboxes,DVD
players,VCRs,etc.)
External AV Source
Supplied RCA Cable
ConnecttheS-VideoportbytheS-Videocabletoinputthevideosignal.S-Videocableisnotincluded1.
withthisproduct
ConnecttheL,Rportbythewhite/redplugofthesuppliedAVcabletoinputtheaudiosignal.2.
External AV Source
ConnecttheVIDEOportwiththeyellowplugofthethesuppliedAVcable.1.
ConnecttheL,Rportwiththewhite/redplugofthesuppliedAVcabletoinputtheaudiosignal.2.
Cable Connections
