Coby TFTV3225S2 - Television Part; SOUND; EXT. TERMINAL; RGB (PC-VGA15) Part

Service Manual
Sep. 30th, 2010 (Version 1.3) Page 5 / 21
 Television Part
Item Specification
TV SYSTEM ATSC/NTSC
CAPTION CLOSED YES
Parental Control YES
PIP/POP NO
TV SYSTEM STEREO/MONO
SOUND OUTPUT 9W X 2
ASP YES
SOUND
EFFECT No
COMPONENT 1
(YPbPr)
Y/Pb/Pr INPUT
AV IN
VIDEO, Y/C INPUT
AUDIO L/R INPUT
PHONES YES
TUNER DIGITAL+Analog tuner(TCL)
EXT.
TERMINAL
VGA(PC) IN
VGA(Analog RGB) INPUT
PC-AUDIO(L/R) INPUT
HDMI IN
DIGITAL AUDIO AND VIDEO (VIDEO AT RESOLUTION UP TO
1080P)
 RGB (PC-VGA15) Part
a. Features of Analog RGB Part
. Horizontal Rate: 31KHz ~ 60KHz
. Vertical Rate: 43 ~ 85Hz
. Maximum Pixel Rate: 78.75MHz
. Resolution Maximum: 32’’ 1280 x 1024
. Color Maximum: 262,114/16.7M(option)
. Sync type: H & V separate
. Plug & Play: YES DDC
b.
This board can detect all VESA standard Graphic modes (for Analog RGB) shown on the table below and provide more
clear and stable image on a screen.
