Coby TFTV3225S2 - Page 6

Service Manual
Sep. 30th, 2010 (Version 1.3) Page 6 / 21
Standard Format Total Pixels x Total Lines
Horizontal rate
(KHz)
Pixel Clock Rate
(MHz)
720 x 400p 70 Hz 900 x 449 31.5 28.0
640 x 480p 60 Hz 800 x525 31.5 25.2
640 x 480p 67Hz 864 x 525 35.0 30.0
640 x 480p 72 Hz 832 x 520 37.9 31.5
VGA
640 x 480p 75 Hz 840 x 500 37.5 31.5
800 x 600 56 Hz 1024 x 625 35.2 36.0
800 x 600 60 Hz 1056 x 628 37.9 40.0
800 x 600 72 Hz 1040 x 666 48.1 50.0
800 x 600 75 Hz 1056 x 625 46.9 49.5
SVGA
832 x 624 75 Hz 1152 x 667 49.7 57.5
1024 x 768 60 Hz 1344 x 806 48.4 65.0
1024 x 768 70 Hz 1328 x 800 56.4 75.0
XGA
1024 x 768 75 Hz 1312 x 800 60.0 79.0
1280 x 1024 75 Hz 1688 x 1066 39.2 135.0
SXGA
1152 x 870 75 Hz 1456 x 916 68.9 100.0
