Coca-Cola FREESTYLE 9000 User Manual

2
| © 2020 The Coca-Cola Company | Coca-Cola Freestyle® 9000 User Guide | Confidential information of The Coca-Cola Company | 20200820
The Coca-Cola Freestyle® 9000 Dispenser is equipped with
a “Status Indicator” light in the upper right corner to notify
the store operator when the dispenser is out of product,
sweetener, or attention is required.
The “status indicator light” turns on as “solid red” or “flashing
red” and generates an error code to signify attention is required
(pictured in the diagram).
Ice bin lid*
Touch screen
Push button
Nozzle & Injector Ring
Ice lever
Cup support
RFID reader
ADA interface
Upper door
Status indicator
Lower door
Manual door release
* Not applicable with top mounted ice maker.
external components
equipmentequipmentequipmentequipment

Coca-Cola FREESTYLE 9000 Specifications

General

Brand	Coca-Cola
Model	FREESTYLE 9000
Category	Dispenser
Language	English
