Code 3 Sprinter User Manual

Hand Held Controller Label Designations and Functions:
Item: Label: Operation: Activation: Description:
Bargraph located between the
Display CLEAR and EMERGENCY lighted postion along displays a series of
keys on the controller bar lights in 6 positions
along bar
LIGHTING CONTROLS:
Item: Label: Operation: Activation: Description:
1. PRIMARY Turns on/off primary front directional and corner
warning lights
2. SEC Turns on/off secondary rear directional
warning lights
3. Turns on/off takedown lights
4. Turns on/off left alley light
5. Turns on/off right alley light
6. LIGHT Turns on/off sign light
7. Turns on/off headlamp asher (both keys pressed together)
8. SEC Turns on/off intersection lights (both keys pressed together)
9. CLEAR Turns off all warning lights
and sirens
SIREN CONTROLS:
10. WAIL YELP Turns on/off Wail-Yelp Siren (default: std. Wail-Yelp)
11. SIREN 2 Turns on/off 2nd siren (default: Hi-Lo)
12. MAN Turns on manual siren while
button is depressed (default: Manual Wail) Returns to previous
siren when
released.
13. EMERGENCY Activates pre-set light and Press EMERGENCY
siren warnings button once.
(OR) Pressing CLEAR
Alternates yelp/wail if siren Press EMERGENCY will turn off the
is currently activated button additional times. EMERGENCY
function including
all lights and sirens.
