Press ALT key to exit programming and save or press CLEAR to exit programming without saving.
HORN RING TRANSFER FUNCTION:
The connection process is the same as standard Sprinter unit. CONNECTING THE GREY WIRE TO
GROUND WILL ACTIVATE THE HORN RING FUNCTION.
When the Wail key is depressed, grey wire has the same function with Emergency key, using to shift
between Wail and Yelp.
TROUBLESHOOTING:
PROBLEM PROBABLE CAUSE REMEDY
No siren output shorted speaker or speaker wires check connecons and wire ways
Fuse Blows amplier wires reversed polarity check polarity of wire connecons
Siren tone volume low or garbled low voltage to siren amplier, high
resistance in wiring/ defecve spkr.
check wiring for bad connecons,
check spkr wiring, replace speaker
High rate of speaker failures high voltage to siren, 58 W speaker
connected-(58 W spkr not allowed)
check vehicle charging system,
install 100W speaker in system
Backlight will not light or adjust parklight input must have +24V for
backlight to funcon on controller
engage parklights on vehicle if
wired into system. or apply +24V.
to parklight circuit input on Amp.
Auxiliary lights do not operate IE:
alley, TD , sign board, headlight
ashers
short ciruit of wiring for light in
queson, internal fuse blown in
amplier
check wiring and connecons to
lights in queson, check and re-
place fuse in amplier circuit
SPECIFICATIONS AND MAINTENANCE:
Specications:
Siren Section
Input Voltage 24VDC (negative ground)
Input Current 5 Amps @ 27.2VDC
Output Voltage Maximum 100W @ 24VDC
Operating Temperature -30 °C to +65 °C
Dimensions (HWL):
Handheld controller 0.65”X 2.0”X3.7”
Amplier 2.0″X3.6″X7.6″
Weight – Siren (approx): 4.0 lbs
Weight – Controller (approx): 0.5 lbs
Base: Black powder coat painted aluminum extrusion
Mounting – Siren: 4-hole ange mounting on base
Mounting – Controller: (Not specied), (4 mounting holes provided on base)
Compliance: SAE J1849, California Title 13
Warranty: 5 years
T56095 Rev. A Page 19 of 22
