Controls and
Operation
The front-panel control on the Codex USB D/A
converter is a combination volume knob and
momentary push switch. The display provides all
information needed for easy operation.
The master power switch is on the rear panel above
the AC mains connector.
Display
Higher sampling rates can
provide higher sound quality.
“64” indicates the incoming
signal is standard DSD-64,
while “128”indicates
double-rate DSD-128.
When playing music, the display will show the
sample rate (in kHz) of the incoming audio data.
When the volume is changed, the volume level (0 to
100) will be displayed for three seconds before
reverting to the sample rate.
Volume Control
The volume control ranges from 0 to 100 in 1.0 dB
steps. It also has a switch activated by pressing the
knob. This controls both the mute and setup menu
functions.
11
