Numbers and
Specifications
Audio Input Signal 44.1, 48, 88.2, 96,
176.4, 192, 352.8 and 384 kHz PCM
16, 20, and 24 bits
2.8224 and 5.6448 MHz DSD
1 bit (DSD over PCM = “DoP”)
Maximum Output Level
Headphone or Preamp Modes
7.2 V RMS – balanced outputs
3.1 V RMS – single-ended outputs
Maximum Output Level
DAC Mode
4.0 V RMS – balanced outputs
2.0 V RMS – single-ended outputs
Analog XLR Output Polarity Pin 1 = Ground
Pin 2 = Non-inverting (Positive)
Pin 3 = Inverting (Negative)
Power Consumption 28 watts
Dimensions 2-¼" W x 9" D x 5-¼" H
5.5 cm x 23 cm x 13.7 cm
Weight 3 pounds
1.4 kg
