The connection to the USB port must be made using a cable no more than 3 metres long.
2.4.2.- Computer.
The Compact Lyon Digital Control Panel system can use software (EASYConet), with which the
user can completely programme the control panel, easily and intuitively. By using this system, the
configuration can be saved for future use.
Minimum PC Configuration:
Pentium IV
Windows XP SP2
128 Mbytes of RAM
50 Mbytes of free space in the Hard Disk
CD-ROM
Minimum resolution 1024x768
Free USB port
As shown in the diagram the connection between the PC and the control panel must be made using a
USB 2.0 PORT.
.
USB Conector
type A
USB Conector
type B
The use of the EASYcoNET program and the configuration of the communication ports of the
computer are described in the manual (Manual EASYcoNET).
In case of installing the ON-LINE functionality of the EASY coNET, instead of using the USB
connection, it must be used the RS485 one indicated as PC on the Control Panel label. This allows avoiding
possible communication interferences and longer separation distances between Control Panel and PC. It is
shown some examples of connection in the following figure.
