CognitiveTPG Advantage LX - Communication Interfaces

6
Advantage LX Communication Interfaces (2” and 4” Model Detail)
Inside View
Common Components for All Models (Direct Thermal and Thermal Transfer)
(TT Printer Shown)
A
B
C
C
D
2” 4”
KEY DC SERIAL 9-PIN ETHERNET CENTRONICS
(DTE Device) Parallel 1284-B
NOTE: Interfaces shown apply to Advantage LX printers with S/N’s starting with “L”
