MACHINE STRUCTURE
PR750H
1 Pellet outlet sprout
2 Hydraulic station
3 Main hydraulic cylinder
4 Touch panel
5 Extruder plate cylinder
6 Extruder plate changer
7 Connection to an external supply, CO
2
in and Out
