4-19 Control Functions
Starter (choke) “ ”
Starting a cold engine requires a richer
air-fuel mixture. A separate choke cable
supplies this mixture.
Move in direction to open choke
Move in direction to turn close choke
Refer to “Starting a cold engine” for proper
operation. (See pages 6-1 - 6-3.)
A. Choke knob 1. Fully open
2. Half open 3. Closed
Seats
To remove the seat bench, pull front of seat
upward, then slide seat forward.
1. Driver / Passenger seat
To install seat bench, insert tabs on rear of
seat into the seat holders located on the UTV
frame. Push down the front of the seat until it
snaps in place.
