Coleman 5600 Series User Manual

ÖÖ
NOTE: The Grill Lids should
be opened for Step 9.
ÖÖ
Assemble Right Side Table to
the Grill.
Step
9
9-A
9-B
9-C
9-A. Raise the Grill Lids.
ÖÖ
Place the Right Side Table against the
Firebox and on top of the Right Rear
Panel.
Hardware shown actual size
(TN)
M6 x 15mm Screw
(4) Qty.
9-B. LOOSELY install four Screws (TN)
upward through the Flange of the Right
Rear Panel into the Right Side Table.
ÖÖ
NOTE: You will tighten these screws
LATER (during Step 10-C), after all eight
Screws (TN) are installed in Step 9 and
Step 10 (this helps with alignment).
Right Side
Table
Right Rear
Panel
Flange
TN (x4)
Firebox
14
