5547666-CTG-A-0718
Johnson Controls Unitary Products 103
COIL MULTIPLIERS - 2 TON
Air Handler Coil T.C. S.C. KW
AE24BBA21 – 1.00 1.00 1.00
AE24BX21 – 1.00 1.00 1.00
AE30BX21 – 0.95 1.03 0.94
AVC24BX21 – 0.95 1.00 0.96
AVC30BX21 – 0.95 1.06 0.96
AVC36BX21 – 0.95 1.06 0.98
AVC36CX21 – 0.95 0.95 0.96
ME08BN21 CF/CM24B 0.98 1.07 0.96
ME08BN21 CF/CM30B 1.01 1.14 1.01
ME08BN21 CF/CM36B 0.95 1.04 0.96
ME08BN21 CM24BBAA1 0.98 1.07 0.96
MVC08BN21 CF/CM24B 0.95 1.03 0.96
MVC08BN21 CF/CM30B 0.95 1.03 1.00
MVC08BN21 CF/CM36B 0.95 1.03 0.98
MVC08BN21 CF24BBAA1 0.95 1.03 0.96
MVC12BN21 CF/CM24B 0.95 1.00 0.98
MVC12BN21 CF/CM30B 0.95 1.03 1.00
MVC12BN21 CF/CM36B 0.98 1.08 1.12
MVC12BN21 CF24BBAA1 0.95 1.00 0.98
MVC14DN21 CF/CM30D 1.00 1.13 1.17
MVC14DN21 CF/CM36D 1.00 1.13 1.20
MVC16CN21 CF/CM30C 0.95 0.97 1.00
MVC16CN21 CF/CM36C 0.95 1.05 1.02
FURNACE MULTIPLIERS - 2 TON
Furnaces Coil T.C. S.C. KW
TM8V060A12MP12C CF/CM/CU24A 0.95 1.00 1.00
TM8V060A12MP12C CF/CM/CU30A 0.95 0.93 1.00
TM8V060A12MP12C CF/CM36A 0.98 1.04 1.00
TM8V060A12MP12C CF24ABAA1 0.95 1.00 1.00
TM8V060A12MP12C CF30ABAA1 0.95 0.93 1.00
TM8V080B12MP12C CF/CM/CU24B 0.95 1.05 0.98
TM8V080B12MP12C CF/CM/CU30B 0.95 0.99 0.98
TM8V080B12MP12C CF/CM/CU36B 0.95 1.00 0.98
TM8V080B12MP12C CF24BBAA1 0.95 1.05 0.98
TM8V080C16MP12C CF/CM/CU24C 0.95 1.00 1.00
TM8V080C16MP12C CF/CM/CU30C 0.95 1.00 1.00
TM8V080C16MP12C CF/CM/CU36C 0.95 1.01 0.98
TM8V100C16MP12C CF/CM/CU24C 0.95 1.00 1.00
TM8V100C16MP12C CF/CM/CU30C 0.95 1.00 1.00
TM8V100C16MP12C CF/CM/CU36C 0.95 1.01 0.98
TM8X060A12MP11 CF/CM/CU24A 0.95 1.02 0.98
TM8X060A12MP11 CF/CM/CU30A 0.95 0.99 0.96
TM8X060A12MP11 CF/CM36A 0.95 0.95 0.98
TM8X060A12MP11 CF24ABAA1 0.95 1.02 0.98
TM8X060A12MP11 CF30ABAA1 0.95 0.99 0.96
TM8X080B12MP11 CF/CM/CU24B 0.95 0.89 0.98
TM8X080B12MP11 CF/CM/CU30B 0.95 0.97 0.98
TM8X080B12MP11 CF/CM/CU36B 0.95 0.95 0.98
TM8X080B12MP11 CF24BBAA1 0.95 0.89 0.98
TM8Y060A12MP11 CF/CM/CU24A 0.95 1.02 0.98
TM8Y060A12MP11 CF/CM/CU30A 0.95 0.99 0.96
TM8Y060A12MP11 CF/CM36A 0.95 0.95 0.98
TM8Y060A12MP11 CF24ABAA1 0.95 1.02 0.98
TM8Y060A12MP11 CF30ABAA1 0.95 0.99 0.96
TM8Y080B12MP11 CF/CM/CU24B 0.95 0.89 0.98
TM8Y080B12MP11 CF/CM/CU30B 0.95 0.97 0.98
TM8Y080B12MP11 CF/CM/CU36B 0.95 0.95 0.98
TM8Y080B12MP11 CF24BBAA1 0.95 0.89 0.98
TM9E040A10MP11 CF/CM/CU24A 0.95 1.00 0.98
TM9E040A10MP11 CF/CM/CU30A 0.95 1.04 0.98
TM9E040A10MP11 CF/CM36A 0.95 0.97 1.02
TM9E040A10MP11 CF24ABAA1 0.95 1.00 0.98
TM9E040A10MP11 CF30ABAA1 0.95 1.04 0.98
TM9E060B12MP11 CF/CM/CU24B 0.95 0.95 1.00
TM9E060B12MP11 CF/CM/CU30B 0.95 1.00 1.04
TM9E060B12MP11 CF/CM/CU36B 0.95 1.03 1.00
TM9E060B12MP11 CF24BBAA1 0.95 0.95 1.00
TM9E080B12MP11 CF/CM/CU24B 0.95 1.01 1.00
TM9E080B12MP11 CF/CM/CU30B 0.95 0.99 1.00
TM9E080B12MP11 CF/CM/CU36B 0.95 1.05 1.00
TM9E080B12MP11 CF24BBAA1 0.95 1.01 1.00
TM9V040A10MP12C CF/CM/CU24A 0.95 1.05 1.00
TM9V040A10MP12C CF/CM/CU30A 0.95 1.00 1.00
TM9V040A10MP12C CF/CM36A 0.95 0.97 1.00
TM9V040A10MP12C CF24ABAA1 0.95 1.05 1.00
TM9V040A10MP12C CF30ABAA1 0.95 1.00 1.00
TM9V060B12MP12C CF/CM/CU24B 0.95 1.00 1.04
TM9V060B12MP12C CF/CM/CU30B 0.95 1.00 1.04
TM9V060B12MP12C CF/CM/CU36B 0.95 1.03 1.04
TM9V060B12MP12C CF24BBAA1 0.95 1.00 1.04
TM9V080B12MP12C CF/CM/CU24B 1.01 1.14 1.01
TM9V080B12MP12C CF/CM/CU30B 0.95 1.03 0.96
TM9V080B12MP12C CF/CM/CU36B 0.95 1.06 0.96
TM9V080B12MP12C CF24BBAA1 1.01 1.14 1.01
TM9V080C16MP12C CF/CM/CU24C 0.95 0.95 0.98
TM9V080C16MP12C CF/CM/CU30C 0.95 0.98 0.98
TM9V080C16MP12C CF/CM/CU36C 0.95 1.02 0.98
TM9V100C16MP12C CF/CM/CU24C 0.95 1.06 0.96
TM9V100C16MP12C CF/CM/CU30C 0.95 0.95 0.96
TM9V100C16MP12C CF/CM/CU36C 0.95 1.06 0.96
TM9Y040A10MP11 CF/CM/CU24A 0.95 1.00 0.98
TM9Y040A10MP11 CF/CM/CU30A 0.95 1.04 0.98
TM9Y040A10MP11 CF/CM36A 0.95 0.97 1.02
TM9Y040A10MP11 CF24ABAA1 0.95 1.00 0.98
TM9Y040A10MP11 CF30ABAA1 0.95 1.04 0.98
TM9Y060B12MP11 CF/CM/CU24B 0.95 0.95 1.00
TM9Y060B12MP11 CF/CM/CU30B 0.95 1.00 1.04
TM9Y060B12MP11 CF/CM/CU36B 0.95 1.03 1.00
TM9Y060B12MP11 CF24BBAA1 0.95 0.95 1.00
TM9Y080B12MP11 CF/CM/CU24B 0.95 1.01 1.00
TM9Y080B12MP11 CF/CM/CU30B 0.95 0.99 1.00
TM9Y080B12MP11 CF/CM/CU36B 0.95 1.05 1.00
TM9Y080B12MP11 CF24BBAA1 0.95 1.01 1.00
TMLV060A12MP12C CF/CM/CU24A 0.95 1.00 1.00
TMLV060A12MP12C CF/CM/CU30A 0.95 0.93 1.00
TMLV060A12MP12C CF/CM36A 0.98 1.04 1.00
TMLV060A12MP12C CF24ABAA1 0.95 1.00 1.00
TMLV060A12MP12C CF30ABAA1 0.95 0.93 1.00
TMLV080B12MP12C CF/CM/CU24B 0.95 1.05 0.98
FURNACE MULTIPLIERS - 2 TON (Continued)
Furnaces Coil T.C. S.C. KW
