5547666-CTG-A-0718
Johnson Controls Unitary Products 115
TMLV080B12MP12C CF/CM/CU30B 1.01 1.01 0.99
TMLV080B12MP12C CF/CM/CU36B 1.01 1.01 0.99
TMLV080B12MP12C CF24BBAA1 1.00 1.01 0.99
TMLV080C16MP12C CF/CM/CU24C 1.00 0.99 1.01
TMLV080C16MP12C CF/CM/CU30C 1.00 0.99 1.01
TMLV080C16MP12C CF/CM/CU36C 1.00 1.00 1.00
TMLV100C16MP12C CF/CM/CU24C 1.00 0.99 1.01
TMLV100C16MP12C CF/CM/CU30C 1.00 0.99 1.01
TMLV100C16MP12C CF/CM/CU36C 1.00 1.00 1.00
TMLX060A12MP11 CF/CM/CU24A 1.00 1.00 1.00
TMLX060A12MP11 CF/CM/CU30A 1.01 1.00 0.99
TMLX060A12MP11 CF/CM36A 1.02 1.01 0.97
TMLX060A12MP11 CF24ABAA1 1.00 1.00 1.00
TMLX060A12MP11 CF30ABAA1 1.01 1.00 0.99
TMLX080B12MP11 CF/CM/CU24B 1.03 1.00 0.97
TMLX080B12MP11 CF/CM/CU30B 1.02 1.01 0.97
TMLX080B12MP11 CF/CM/CU36B 1.02 1.01 0.97
TMLX080B12MP11 CF24BBAA1 1.03 1.00 0.97
TP9C060B12MP13C CF/CM/CU24B 0.99 0.99 1.01
TP9C060B12MP13C CF/CM/CU30B 0.98 0.97 1.05
TP9C060B12MP13C CF/CM/CU36B 1.01 1.02 0.96
TP9C060B12MP13C CF24BBAA1 0.99 0.99 1.01
TP9C080B12MP13C CF/CM/CU24B 1.01 1.02 0.97
TP9C080B12MP13C CF/CM/CU30B 1.01 1.00 0.99
TP9C080B12MP13C CF/CM/CU36B 1.00 1.00 1.00
TP9C080B12MP13C CF24BBAA1 1.01 1.02 0.97
TP9C080C16MP13C CF/CM/CU24C 1.02 1.01 0.97
TP9C080C16MP13C CF/CM/CU30C 1.01 1.01 0.98
TP9C080C16MP13C CF/CM/CU36C 1.00 1.01 0.99
TP9C100C16MP13C CF/CM/CU24C 1.00 1.01 0.99
TP9C100C16MP13C CF/CM/CU30C 1.03 1.01 0.97
TP9C100C16MP13C CF/CM/CU36C 1.00 1.01 0.99
TPLC060A12MP13C CF/CM/CU24A 1.01 0.98 1.01
TPLC060A12MP13C CF/CM/CU30A 1.02 0.97 1.01
TPLC060A12MP13C CF/CM36A 1.01 1.01 0.99
TPLC060A12MP13C CF24ABAA1 1.01 0.98 1.01
TPLC060A12MP13C CF30ABAA1 1.02 0.97 1.01
TPLC080B12MP13C CF/CM/CU24B 1.00 1.01 0.99
TPLC080B12MP13C CF/CM/CU30B 1.01 1.01 0.99
FURNACE MULTIPLIERS - 2 TON (Continued)
Furnaces Coil MBH COP KW
TPLC080B12MP13C CF/CM/CU36B 1.01 1.01 0.99
TPLC080B12MP13C CF24BBAA1 1.00 1.01 0.99
TPLC080C16MP13C CF/CM/CU24C 1.00 0.99 1.01
TPLC080C16MP13C CF/CM/CU30C 1.00 0.99 1.01
TPLC080C16MP13C CF/CM/CU36C 1.00 1.00 1.00
TPLC100C16MP13C CF/CM/CU24C 1.00 0.99 1.01
TPLC100C16MP13C CF/CM/CU30C 1.00 0.99 1.01
TPLC100C16MP13C CF/CM/CU36C 1.00 1.00 1.00
CP9C060B12MP13C CF/CM/CU24B 0.99 0.99 1.01
CP9C060B12MP13C CF/CM/CU30B 0.98 0.97 1.05
CP9C060B12MP13C CF/CM/CU36B 1.01 1.02 0.96
CP9C060B12MP13C CF24BBAA1 0.99 0.99 1.01
CP9C080B12MP13C CF/CM/CU24B 1.01 1.02 0.97
CP9C080B12MP13C CF/CM/CU30B 1.01 1.00 0.99
CP9C080B12MP13C CF/CM/CU36B 1.00 1.00 1.00
CP9C080B12MP13C CF24BBAA1 1.01 1.02 0.97
CP9C080C16MP13C CF/CM/CU24C 1.02 1.01 0.97
CP9C080C16MP13C CF/CM/CU30C 1.01 1.01 0.98
CP9C080C16MP13C CF/CM/CU36C 1.00 1.01 0.99
CP9C100C16MP13C CF/CM/CU24C 1.00 1.01 0.99
CP9C100C16MP13C CF/CM/CU30C 1.03 1.01 0.97
CP9C100C16MP13C CF/CM/CU36C 1.00 1.01 0.99
CPLC060A12MP13C CF/CM/CU24A 1.01 0.98 1.01
CPLC060A12MP13C CF/CM/CU30A 1.02 0.97 1.01
CPLC060A12MP13C CF/CM36A 1.01 1.01 0.99
CPLC060A12MP13C CF24ABAA1 1.01 0.98 1.01
CPLC060A12MP13C CF30ABAA1 1.02 0.97 1.01
CPLC080B12MP13C CF/CM/CU24B 1.00 1.01 0.99
CPLC080B12MP13C CF/CM/CU30B 1.01 1.01 0.99
CPLC080B12MP13C CF/CM/CU36B 1.01 1.01 0.99
CPLC080B12MP13C CF24BBAA1 1.00 1.01 0.99
CPLC080C16MP13C CF/CM/CU24C 1.00 0.99 1.01
CPLC080C16MP13C CF/CM/CU30C 1.00 0.99 1.01
CPLC080C16MP13C CF/CM/CU36C 1.00 1.00 1.00
CPLC100C16MP13C CF/CM/CU24C 1.00 0.99 1.01
CPLC100C16MP13C CF/CM/CU30C 1.00 0.99 1.01
CPLC100C16MP13C CF/CM/CU36C 1.00 1.00 1.00
FURNACE MULTIPLIERS - 2 TON (Continued)
Furnaces Coil MBH COP KW
EXTENDED RANGE HEATING DATA
CONDENSING UNIT MODEL NO CH16B2421S
AIR TEMP.
ENTERING
OUTDOOR UNIT (°F)
AIR TEMP.
ENTERING
INDOOR COIL (°F)
ID CFM
550 750 950
MBH COP KW MBH COP KW MBH COP KW
0
60 11.0 2.16 1.50 11.8 2.24 1.55 13.5 2.33 1.70
70 9.9 1.98 1.47 10.5 2.02 1.50 10.9 1.96 1.63
80 9.2 1.86 1.45 8.2 1.66 1.40 9.4 1.81 1.52
-10
60 9.1 1.88 1.44 9.8 1.95 1.49 11.2 2.03 1.64
70 8.2 1.73 1.41 8.7 1.76 1.44 9.0 1.71 1.57
80 7.6 1.62 1.40 6.8 1.45 1.35 7.7 1.58 1.46
-20
60 7.2 1.60 1.38 7.7 1.66 1.43 8.8 1.73 1.57
70 6.4 1.48 1.35 6.8 1.51 1.38 7.0 1.47 1.50
80 6.0 1.38 1.34 5.3 1.23 1.29 6.1 1.34 1.40
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
