Coleman CH16B6021S - Page 141

5547666-CTG-A-0718
Johnson Controls Unitary Products 141
COIL MULTIPLIERS - 4 TON
Air Handler Coil T.C. S.C. KW
AE48CBC21 – 1.00 1.00 1.00
AE48CX21 – 1.00 1.00 1.00
AE48DBC21 – 1.00 1.12 1.05
AE48DX21 – 1.00 1.12 1.05
AVC48CX21 – 0.99 1.05 1.04
AVC48DX21 – 1.01 1.12 1.03
AVC60CX21 – 1.00 1.06 1.05
AVC60DX21 – 1.02 1.12 1.04
ME14DN21 CF/CM64D 1.02 1.11 1.04
MVC14DN21 CF/CM48D 1.02 1.14 1.04
MVC16CN21 CF/CM48C 1.01 1.11 1.03
MVC16CN21 CF/CM60C 1.02 1.12 1.04
MVC16CN21 CF48CBCA1 1.01 1.11 1.03
MVC20DN21 CF/CM48D 0.99 1.08 1.04
MVC20DN21 CF/CM60D 1.02 1.11 1.02
MVC20DN21 CF/CM64D 1.02 1.17 1.02
FURNACE MULTIPLIERS - 4 TON
Furnaces Coil T.C. S.C. KW
TM8V080B12MP12C CF/CM/CU48C 0.97 1.01 1.07
TM8V080B12MP12C CF/CM/CU60C 0.98 1.01 1.08
TM8V080B12MP12C CF48CBCA1 0.97 1.01 1.07
TM8V080C16MP12C CF/CM/CU48C 0.98 1.04 1.02
TM8V080C16MP12C CF/CM/CU48D 0.99 1.05 1.04
TM8V080C16MP12C CF/CM/CU60C 1.00 1.06 1.05
TM8V080C16MP12C CF/CM/CU60D 1.00 1.06 1.05
TM8V080C16MP12C CF/CM64D 1.01 1.07 1.03
TM8V080C16MP12C CF48CBCA1 0.98 1.04 1.02
TM8V100C16MP12C CF/CM/CU48C 0.98 1.04 1.02
TM8V100C16MP12C CF/CM/CU48D 0.99 1.05 1.04
TM8V100C16MP12C CF/CM/CU60C 1.00 1.06 1.05
TM8V100C16MP12C CF/CM/CU60D 1.00 1.06 1.05
TM8V100C16MP12C CF/CM64D 1.01 1.07 1.03
TM8V100C16MP12C CF48CBCA1 0.98 1.04 1.02
TM8V100C20MP12C CF/CM/CU48C 0.99 1.07 1.04
TM8V100C20MP12C CF/CM/CU48D 1.00 1.09 1.05
TM8V100C20MP12C CF/CM/CU60C 1.01 1.09 1.03
TM8V100C20MP12C CF/CM/CU60D 1.01 1.09 1.03
TM8V100C20MP12C CF/CM64D 1.01 1.05 1.03
TM8V100C20MP12C CF48CBCA1 0.99 1.07 1.04
TM8V120C20MP12C CF/CM/CU48C 0.99 1.07 1.04
TM8V120C20MP12C CF/CM/CU48D 1.00 1.09 1.05
TM8V120C20MP12C CF/CM/CU60C 1.01 1.09 1.03
TM8V120C20MP12C CF/CM/CU60D 1.01 1.09 1.03
TM8V120C20MP12C CF/CM64D 1.01 1.05 1.03
TM8V120C20MP12C CF48CBCA1 0.99 1.07 1.04
TM8X080C16MP11 CF/CM/CU48C 0.98 1.07 1.08
TM8X080C16MP11 CF/CM/CU48D 0.98 1.07 1.08
TM8X080C16MP11 CF/CM/CU60C 1.01 1.10 1.06
TM8X080C16MP11 CF/CM/CU60D 1.01 1.11 1.06
TM8X080C16MP11 CF/CM64D 1.02 1.11 1.07
TM8X080C16MP11 CF48CBCA1 0.98 1.07 1.08
TM8X100C16MP11 CF/CM/CU48C 0.98 1.07 1.08
TM8X100C16MP11 CF/CM/CU48D 0.98 1.07 1.08
TM8X100C16MP11 CF/CM/CU60C 1.01 1.10 1.06
TM8X100C16MP11 CF/CM/CU60D 1.01 1.11 1.06
TM8X100C16MP11 CF/CM64D 1.02 1.11 1.07
TM8X100C16MP11 CF48CBCA1 0.98 1.07 1.08
TM8X100C20MP11 CF/CM/CU48C 1.00 1.09 1.05
TM8X100C20MP11 CF/CM/CU48D 0.99 1.09 1.06
TM8X100C20MP11 CF/CM/CU60C 1.01 1.10 1.06
TM8X100C20MP11 CF/CM/CU60D 1.02 1.18 1.07
TM8X100C20MP11 CF/CM64D 1.02 1.11 1.07
TM8X100C20MP11 CF48CBCA1 1.00 1.09 1.05
TM8X120C20MP11 CF/CM/CU48C 1.00 1.09 1.05
TM8X120C20MP11 CF/CM/CU48D 0.99 1.09 1.06
TM8X120C20MP11 CF/CM/CU60C 1.01 1.10 1.06
TM8X120C20MP11 CF/CM/CU60D 1.02 1.18 1.07
TM8X120C20MP11 CF/CM64D 1.02 1.11 1.07
TM8X120C20MP11 CF48CBCA1 1.00 1.09 1.05
TM8Y080C16MP11 CF/CM/CU48C 0.98 1.07 1.08
TM8Y080C16MP11 CF/CM/CU48D 0.98 1.07 1.08
TM8Y080C16MP11 CF/CM/CU60C 1.01 1.10 1.06
TM8Y080C16MP11 CF/CM/CU60D 1.01 1.11 1.06
TM8Y080C16MP11 CF/CM64D 1.02 1.11 1.07
TM8Y080C16MP11 CF48CBCA1 0.98 1.07 1.08
TM8Y100C16MP11 CF/CM/CU48C 0.98 1.07 1.08
TM8Y100C16MP11 CF/CM/CU48D 0.98 1.07 1.08
TM8Y100C16MP11 CF/CM/CU60C 1.01 1.10 1.06
TM8Y100C16MP11 CF/CM/CU60D 1.01 1.11 1.06
TM8Y100C16MP11 CF/CM64D 1.02 1.11 1.07
TM8Y100C16MP11 CF48CBCA1 0.98 1.07 1.08
TM8Y100C20MP11 CF/CM/CU48C 1.00 1.09 1.05
TM8Y100C20MP11 CF/CM/CU48D 0.99 1.09 1.06
TM8Y100C20MP11 CF/CM/CU60C 1.01 1.10 1.06
TM8Y100C20MP11 CF/CM/CU60D 1.02 1.18 1.07
TM8Y100C20MP11 CF/CM64D 1.02 1.11 1.07
TM8Y100C20MP11 CF48CBCA1 1.00 1.09 1.05
TM8Y120C20MP11 CF/CM/CU48C 1.00 1.09 1.05
TM8Y120C20MP11 CF/CM/CU48D 0.99 1.09 1.06
TM8Y120C20MP11 CF/CM/CU60C 1.01 1.10 1.06
TM8Y120C20MP11 CF/CM/CU60D 1.02 1.18 1.07
TM8Y120C20MP11 CF/CM64D 1.02 1.11 1.07
TM8Y120C20MP11 CF48CBCA1 1.00 1.09 1.05
TM9E080B12MP11 CF/CM/CU48C 0.99 1.07 1.09
TM9E080B12MP11 CF/CM/CU60C 1.00 1.08 1.07
TM9E080B12MP11 CF48CBCA1 0.99 1.07 1.09
TM9E080C16MP11 CF/CM/CU48C 1.00 1.09 1.07
TM9E080C16MP11 CF/CM/CU48D 1.00 1.10 1.07
TM9E080C16MP11 CF/CM/CU60C 1.00 1.09 1.07
TM9E080C16MP11 CF/CM/CU60D 1.00 1.10 1.07
TM9E080C16MP11 CF/CM64D 1.02 1.12 1.10
TM9E080C16MP11 CF48CBCA1 1.00 1.09 1.07
TM9E100C16MP11 CF/CM/CU48C 1.00 1.10 1.07
TM9E100C16MP11 CF/CM/CU48D 1.00 1.10 1.07
TM9E100C16MP11 CF/CM/CU60C 1.01 1.11 1.09
TM9E100C16MP11 CF/CM/CU60D 1.01 1.12 1.09
TM9E100C16MP11 CF/CM64D 1.02 1.12 1.10
TM9E100C16MP11 CF48CBCA1 1.00 1.10 1.07
TM9E100C20MP11 CF/CM/CU48C 1.00 1.08 1.05
FURNACE MULTIPLIERS - 4 TON (Continued)
Furnaces Coil T.C. S.C. KW
