5547666-CTG-A-0718
144 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 °F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA - MEDIUM
AIR CONDITIONER MODEL NO. CH16B4821S
AIR TEMP.
ENTERING
OUTDOOR UNIT (°F)
IDCFM 800 1000 1200
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55
T.C. 28.1 30.8 31.1 36.1 37.8 29.95 31.9 32.2 37.45 38.8 31.8 33 33.3 38.8 39.8
S.C. 27.6 24.6 21 21.6 16.6 29.55 27.45 23.25 23.95 17.85 31.5 30.3 25.5 26.3 19.1
KW 1.41 1.37 1.37 1.51 1.25 1.44 1.42 1.42 1.56 1.30 1.48 1.47 1.47 1.60 1.36
65
T.C. 27.1 29.3 29.8 34.7 37.3 28.9 30.4 30.9 35.9 37.8 30.6 31.5 31.9 37.2 38.3
S.C. 26.7 23.8 20.5 21.0 16.5 28.6 26.6 22.8 23.3 17.6 30.5 29.5 25.1 25.7 18.8
KW 1.61 1.60 1.59 1.76 1.60 1.66 1.65 1.65 1.81 1.60 1.71 1.71 1.71 1.86 1.61
75
T.C. 26.1 27.8 28.5 33.3 36.8 27.8 28.9 29.5 34.4 36.8 29.4 29.9 30.5 35.5 36.8
S.C. 25.8 22.9 19.9 20.4 16.3 27.6 25.8 22.3 22.7 17.4 29.4 28.6 24.6 25.0 18.4
KW 1.82 1.82 1.82 2.00 1.94 1.88 1.89 1.88 2.06 1.90 1.94 1.95 1.94 2.12 1.86
85
T.C. 25.1 26.4 26.9 31.5 35.2 28.4 27.3 27.7 32.5 35.6 31.6 28.3 28.6 33.5 36.1
S.C. 24.9 22.3 19.0 19.7 15.7 28.3 25.0 21.2 21.8 16.9 31.6 27.6 23.4 24.0 18.2
KW 2.03 2.07 2.06 2.28 2.22 2.43 2.14 2.13 2.34 2.24 2.83 2.20 2.20 2.41 2.25
95
T.C. 24.1 25.0 25.2 29.7 33.5 29.0 25.8 26.0 30.6 34.5 33.8 26.6 26.7 31.4 35.4
S.C. 24.0 21.7 18.1 18.9 15.1 28.9 24.2 20.2 20.9 16.5 33.8 26.6 22.2 22.9 17.9
KW 2.24 2.32 2.31 2.55 2.51 2.98 2.39 2.39 2.62 2.58 3.73 2.46 2.46 2.69 2.65
105
T.C. 23.1 23.6 23.6 27.9 31.4 27.3 24.9 24.8 28.6 32.2 31.5 26.2 26.1 29.4 33.1
S.C. 23.1 21.1 17.2 18.3 14.5 27.3 23.6 19.7 20.4 15.9 31.4 26.1 22.1 22.4 17.2
KW 2.45 2.56 2.56 2.86 2.84 3.05 2.77 2.76 2.94 2.92 3.65 2.97 2.96 3.01 2.99
115
T.C. 22.1 22.2 21.9 26.1 29.3 25.7 24.0 23.7 26.8 30.1 29.2 25.9 25.6 27.4 30.8
S.C. 22.0 20.5 16.3 17.8 13.9 25.6 23.1 19.2 19.9 15.2 29.1 25.7 22.1 22.0 16.6
KW 2.65 2.81 2.81 3.17 3.17 3.12 3.14 3.13 3.25 3.24 3.58 3.47 3.44 3.32 3.32
125
T.C. 21.1 20.8 20.3 24.4 27.3 24.1 23.2 22.6 25.0 28.0 27.0 25.5 25.0 25.5 28.6
S.C. 20.9 19.9 15.4 17.2 13.3 23.9 22.6 18.7 19.4 14.6 26.8 25.2 22.0 21.5 15.9
KW 2.86 3.06 3.06 3.48 3.49 3.18 3.51 3.50 3.56 3.57 3.51 3.96 3.93 3.63 3.65
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Green shaded cells are ACCA (TVA) conditions.
Blue shaded cells are AHRI conditions.
COIL MULTIPLIERS - 4 TON
Air Handler Coil T.C. S.C. KW
AE48CBC21 – 1.00 1.00 1.00
AE48CX21 – 1.00 1.00 1.00
AE48DBC21 – 1.01 1.18 0.98
AE48DX21 – 1.01 1.18 0.98
AVC48CX21 – 0.99 1.05 1.04
AVC48DX21 – 1.01 1.12 1.03
AVC60CX21 – 1.00 1.06 1.05
AVC60DX21 – 1.02 1.12 1.04
ME14DN21 CF/CM64D 0.99 1.06 0.95
MVC14DN21 CF/CM48D 1.02 1.14 1.04
MVC16CN21 CF/CM48C 1.01 1.11 1.03
MVC16CN21 CF/CM60C 1.02 1.12 1.04
MVC16CN21 CF48CBCA1 1.01 1.11 1.03
MVC20DN21 CF/CM48D 0.99 1.08 1.04
MVC20DN21 CF/CM60D 1.02 1.11 1.02
MVC20DN21 CF/CM64D 1.02 1.17 1.02
FURNACE MULTIPLIERS - 4 TON
Furnaces Coil T.C. S.C. KW
TM8V080B12MP12C CF/CM/CU48C 0.96 0.97 0.99
TM8V080B12MP12C CF/CM/CU60C 0.96 0.96 0.99
TM8V080B12MP12C CF48CBCA1 0.96 0.97 0.99
TM8V080C16MP12C CF/CM/CU48C 0.97 1.00 0.98
TM8V080C16MP12C CF/CM/CU48D 0.97 1.00 0.98
TM8V080C16MP12C CF/CM/CU60C 0.97 1.00 0.97
TM8V080C16MP12C CF/CM/CU60D 0.97 1.00 0.97
TM8V080C16MP12C CF/CM64D 0.98 1.01 0.97
TM8V080C16MP12C CF48CBCA1 0.97 1.00 0.98
TM8V100C16MP12C CF/CM/CU48C 0.97 1.00 0.98
TM8V100C16MP12C CF/CM/CU48D 0.97 1.00 0.98
TM8V100C16MP12C CF/CM/CU60C 0.97 1.00 0.97
TM8V100C16MP12C CF/CM/CU60D 0.97 1.00 0.97
TM8V100C16MP12C CF/CM64D 0.98 1.01 0.97
TM8V100C16MP12C CF48CBCA1 0.97 1.00 0.98
TM8V100C20MP12C CF/CM/CU48C 0.98 1.02 0.97
TM8V100C20MP12C CF/CM/CU48D 0.98 1.03 0.98
TM8V100C20MP12C CF/CM/CU60C 0.98 1.01 0.97
TM8V100C20MP12C CF/CM/CU60D 0.98 1.01 0.97
TM8V100C20MP12C CF/CM64D 0.98 1.00 0.96
