5547666-CTG-A-0718
152 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA - HIGH
CONDENSING UNIT MODEL NO CH16B4821S
AIR TEMP.
ENTERING
OUTDOOR UNIT (°F)
AIR TEMP.
ENTERING
INDOOR COIL (°F)
ID CFM
1200 1400 1600
MBH COP KW MBH COP KW MBH COP KW
60
60 61.2 3.27 5.48 62.1 3.42 5.32 63.0 3.58 5.15
70 57.7 2.95 5.72 59.7 3.10 5.65 61.8 3.25 5.58
80 54.1 2.69 5.89 57.4 2.83 5.93 60.6 2.97 5.98
47
60 52.7 3.09 5.00 53.5 3.20 4.89 54.3 3.32 4.79
70 51.7 2.81 5.40
52.5 2.92 5.27 53.4 3.05 5.13
80 50.7 2.57 5.78 51.6 2.67 5.66 52.4 2.77 5.53
40
60 48.0 2.95 4.76 48.8 3.05 4.69 49.5 3.14 4.62
70 46.9 2.68 5.14 47.8 2.77 5.05 48.8 2.87 4.97
80 45.8 2.45 5.49 46.9 2.55 5.40 48.0 2.65 5.31
30
60 41.0 2.71 4.43 41.9 2.79 4.40 42.8 2.87 4.37
70 41.0 2.51 4.79 41.7 2.57 4.75 42.4 2.64 4.70
80 41.0 2.34 5.14 41.5 2.39 5.08 42.0 2.45 5.03
17
60 34.7 2.47 4.11 35.2 2.52 4.09 35.7 2.58 4.06
70 33.4 2.24 4.36
34.3 2.31 4.35 35.3 2.38 4.35
80 32.0 2.05 4.57 33.5 2.13 4.60 34.9 2.21 4.63
10
60 30.8 2.34 3.86 31.5 2.38 3.87 32.20 2.43 3.89
70 28.9 2.08 4.06 30.1 2.15 4.11 31.4 2.21 4.16
80 27.0 1.88 4.21 28.8 1.96 4.31 30.5 2.03 4.40
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Yellow shaded cells are AHRI High Heating conditions.
Orange shaded cells are AHRI Low Heating conditions.
COIL MULTIPLIERS - 4 TON
Air Handler Coil MBH COP KW
AE48CBC21 – 1.00 1.00 1.00
AE48CX21 – 1.00 1.00 1.00
AE48DBC21 – 0.98 0.98 1.04
AE48DX21 – 0.98 0.98 1.04
AVC48CX21 – 0.98 0.97 1.05
AVC48DX21 – 0.98 1.02 1.00
AVC60CX21 – 0.99 0.98 1.03
AVC60DX21 – 1.01 1.06 0.94
ME14DN21 CF/CM64D 1.02 1.04 0.94
MVC14DN21 CF/CM48D 0.99 1.01 1.00
MVC16CN21 CF/CM48C 0.99 1.00 1.01
MVC16CN21 CF/CM60C 1.00 1.01 0.99
MVC16CN21 CF48CBCA1 0.99 1.00 1.01
MVC20DN21 CF/CM48D 0.98 0.98 1.05
MVC20DN21 CF/CM60D 1.00 1.02 0.98
MVC20DN21 CF/CM64D 1.01 1.09 0.91
FURNACE MULTIPLIERS - 4 TON
Furnaces Coil MBH COP KW
TM8V080B12MP12C CF/CM/CU48C 0.98 0.94 1.09
TM8V080B12MP12C CF/CM/CU60C 0.98 0.95 1.07
TM8V080B12MP12C CF48CBCA1 0.98 0.94 1.09
TM8V080C16MP12C CF/CM/CU48C 0.98 0.98 1.05
TM8V080C16MP12C CF/CM/CU48D 0.98 0.98 1.05
TM8V080C16MP12C CF/CM/CU60C 0.99 0.98 1.03
TM8V080C16MP12C CF/CM/CU60D 0.99 0.99 1.02
TM8V080C16MP12C CF/CM64D 1.01 1.02 0.97
TM8V080C16MP12C CF48CBCA1 0.98 0.98 1.05
TM8V100C16MP12C CF/CM/CU48C 0.98 0.98 1.05
TM8V100C16MP12C CF/CM/CU48D 0.98 0.98 1.05
TM8V100C16MP12C CF/CM/CU60C 0.99 0.98 1.03
TM8V100C16MP12C CF/CM/CU60D 0.99 0.99 1.02
TM8V100C16MP12C CF/CM64D 1.01 1.02 0.97
TM8V100C16MP12C CF48CBCA1 0.98 0.98 1.05
TM8V100C20MP12C CF/CM/CU48C 0.98 0.99 1.03
TM8V100C20MP12C CF/CM/CU48D 0.98 0.99 1.03
TM8V100C20MP12C CF/CM/CU60C 0.99 1.00 1.01
TM8V100C20MP12C CF/CM/CU60D 0.99 1.01 1.00
TM8V100C20MP12C CF/CM64D 1.02 1.02 0.95
TM8V100C20MP12C CF48CBCA1 0.98 0.99 1.03
TM8V120C20MP12C CF/CM/CU48C 0.98 0.99 1.03
TM8V120C20MP12C CF/CM/CU48D 0.98 0.99 1.03
TM8V120C20MP12C CF/CM/CU60C 0.99 1.00 1.01
TM8V120C20MP12C CF/CM/CU60D 0.99 1.01 1.00
TM8V120C20MP12C CF/CM64D 1.02 1.02 0.95
TM8V120C20MP12C CF48CBCA1 0.98 0.99 1.03
