5547666-CTG-A-0718
156 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA - MEDIUM
CONDENSING UNIT MODEL NO CH16B4821S
AIR TEMP.
ENTERING
OUTDOOR UNIT (°F)
AIR TEMP.
ENTERING
INDOOR COIL (°F)
ID CFM
800 1000 1200
MBH COP KW MBH COP KW MBH COP KW
60
60 32.8 4.24 2.27 33.7 4.49 2.20 34.6 4.76 2.13
70 31.8 3.72 2.50 32.8 3.97 2.42 33.7 4.23 2.33
80 30.8 3.32 2.72 31.8 3.50 2.66 32.8 3.70 2.60
47
60 27.9 3.82 2.14 28.6 3.98 2.11 29.3 4.14 2.08
70 27.1 3.36 2.36
27.9 3.52 2.32 28.7 3.68 2.28
80 26.2 3.01 2.55 27.2 3.16 2.52 28.1 3.32 2.48
40
60 23.9 3.41 2.05 24.3 3.50 2.03 24.6 3.59 2.01
70 22.8 2.99 2.23 23.2 3.09 2.20 23.7 3.19 2.17
80 21.7 2.66 2.39 22.2 2.73 2.39 22.7 2.79 2.38
30
60 20.5 3.06 1.96 21.6 3.19 1.98 22.7 3.32 2.01
70 20.5 2.80 2.14 21.2 2.88 2.16 21.9 2.95 2.17
80 20.5 2.59 2.32 20.8 2.62 2.32 21.1 2.66 2.32
17
60 17.1 2.77 1.81 19.0 2.93 1.89 20.8 3.08 1.98
70 18.2 2.63 2.02
19.2 2.71 2.07 20.2 2.79 2.12
80 19.3 2.51 2.25 19.4 2.53 2.25 19.5 2.55 2.24
10
60 13.7 2.53 1.59 16.3 2.72 1.75 18.90 2.88 1.92
70 15.9 2.48 1.87 17.2 2.57 1.96 18.4 2.64 2.04
80 18.1 2.44 2.17 18.0 2.44 2.16 17.9 2.44 2.15
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Yellow shaded cells are AHRI High Heating conditions.
Orange shaded cells are AHRI Low Heating conditions.
HEATING PERFORMANCE DATA - LOW
CONDENSING UNIT MODEL NO CH16B4821S
AIR TEMP.
ENTERING
OUTDOOR UNIT (°F)
AIR TEMP.
ENTERING
INDOOR COIL (°F)
ID CFM
800 1000 1200
MBH COP KW MBH COP KW MBH COP KW
60
60 26.1 4.63 1.65 26.8 4.75 1.65 27.4 4.88 1.64
70 25.2 4.02 1.83 25.8 4.14 1.83 26.5 4.26 1.82
80 24.2 3.55 2.00 24.9 3.67 1.99 25.5 3.78 1.98
47
60 22.0 3.91 1.65 22.6 3.97 1.66 23.1 4.04 1.67
70 21.2 3.43 1.81 21.8 3.50 1.82 22.4 3.57 1.83
80 20.4 3.06 1.96 21.0 3.13 1.97 21.6 3.20 1.98
40
60 20.0 3.59 1.63 20.5 3.64 1.65 21.0 3.70 1.66
70 19.3 3.18 1.78 19.8 3.23 1.79 20.3 3.29 1.81
80 18.6 2.86 1.91 19.1 2.91 1.93 19.6 2.95 1.94
30
60 16.7 3.11 1.57 17.0 3.08 1.62 17.3 3.06 1.66
70 16.4 2.80 1.71 16.7 2.80 1.75 17.0 2.79 1.79
80 16.0 2.55 1.84 16.4 2.56 1.87 16.7 2.57 1.91
17
60 13.4 2.75 1.43 13.5 2.67 1.48 13.6 2.60 1.53
70 13.4 2.50 1.57 13.6 2.46 1.61 13.7 2.42 1.66
80 13.4 2.30 1.71 13.6 2.28 1.75 13.8 2.27 1.78
10
60 10.1 2.46 1.20 10.0 2.36 1.24 9.90 2.27 1.28
70 10.5 2.26 1.35 10.4 2.20 1.39 10.4 2.14 1.42
80 10.8 2.09 1.51 10.9 2.06 1.54 10.9 2.03 1.57
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Yellow shaded cells are AHRI High Heating conditions.
Orange shaded cells are AHRI Low Heating conditions.
