Coleman CH16B6021S - Page 162

5547666-CTG-A-0718
162 Johnson Controls Unitary Products
COIL MULTIPLIERS - 5 TON
Air Handler Coil T.C. S.C. KW
AE60DBG21 – 1.00 1.00 1.00
AE60DX21 – 1.00 1.00 1.00
AVC60DX21 – 0.99 1.00 0.98
MVC20DN21 CF/CM64D 1.03 1.13 0.99
FURNACE MULTIPLIERS - 5 TON
Furnaces Coil T.C. S.C. KW
TM8V080C16MP12C CF/CM/CU48C 0.96 0.98 1.00
TM8V080C16MP12C CF/CM/CU48D 0.96 0.98 0.98
TM8V080C16MP12C CF/CM/CU60C 0.97 0.99 0.99
TM8V080C16MP12C CF/CM/CU60D 0.97 0.99 0.99
TM8V100C16MP12C CF/CM/CU48C 0.96 0.98 1.00
TM8V100C16MP12C CF/CM/CU48D 0.96 0.98 0.98
TM8V100C16MP12C CF/CM/CU60C 0.97 0.99 0.99
TM8V100C16MP12C CF/CM/CU60D 0.97 0.99 0.99
TM8V100C20MP12C CF/CM/CU48C 0.96 0.95 0.97
TM8V100C20MP12C CF/CM/CU48D 0.96 0.98 0.98
TM8V100C20MP12C CF/CM/CU60C 0.97 0.97 0.99
TM8V100C20MP12C CF/CM/CU60D 0.97 0.99 0.99
TM8V100C20MP12C CF/CM64D 0.99 1.01 0.98
TM8V120C20MP12C CF/CM/CU48C 0.96 0.95 0.97
TM8V120C20MP12C CF/CM/CU48D 0.96 0.98 0.98
TM8V120C20MP12C CF/CM/CU60C 0.97 0.97 0.99
TM8V120C20MP12C CF/CM/CU60D 0.97 0.99 0.99
TM8V120C20MP12C CF/CM64D 0.99 1.01 0.98
TM8X080C16MP11 CF/CM/CU48C 0.94 0.94 1.00
TM8X080C16MP11 CF/CM/CU48D 0.94 0.94 1.00
TM8X080C16MP11 CF/CM/CU60C 0.98 1.03 1.02
TM8X080C16MP11 CF/CM/CU60D 0.97 0.98 1.01
TM8X080C16MP11 CF/CM64D 1.00 1.04 1.02
TM8X100C16MP11 CF/CM/CU48C 0.94 0.94 1.00
TM8X100C16MP11 CF/CM/CU48D 0.94 0.94 1.00
TM8X100C16MP11 CF/CM/CU60C 0.98 1.03 1.02
TM8X100C16MP11 CF/CM/CU60D 0.97 0.98 1.01
TM8X100C16MP11 CF/CM64D 1.00 1.04 1.02
TM8X100C20MP11 CF/CM/CU48C 0.94 0.94 1.00
TM8X100C20MP11 CF/CM/CU48D 0.95 0.95 0.99
TM8X100C20MP11 CF/CM/CU60C 0.97 0.97 0.99
TM8X100C20MP11 CF/CM/CU60D 0.98 0.99 1.00
TM8X100C20MP11 CF/CM64D 0.99 0.99 0.98
TM8X120C20MP11 CF/CM/CU48C 0.94 0.94 1.00
TM8X120C20MP11 CF/CM/CU48D 0.95 0.95 0.99
TM8X120C20MP11 CF/CM/CU60C 0.97 0.97 0.99
TM8X120C20MP11 CF/CM/CU60D 0.98 0.99 1.00
TM8X120C20MP11 CF/CM64D 0.99 0.99 0.98
TM8Y080C16MP11 CF/CM/CU48C 0.94 0.94 1.00
TM8Y080C16MP11 CF/CM/CU48D 0.94 0.94 1.00
TM8Y080C16MP11 CF/CM/CU60C 0.98 1.03 1.02
TM8Y080C16MP11 CF/CM/CU60D 0.97 0.98 1.01
TM8Y080C16MP11 CF/CM64D 1.00 1.04 1.02
TM8Y100C16MP11 CF/CM/CU48C 0.94 0.94 1.00
TM8Y100C16MP11 CF/CM/CU48D 0.94 0.94 1.00
TM8Y100C16MP11 CF/CM/CU60C 0.98 1.03 1.02
TM8Y100C16MP11 CF/CM/CU60D 0.97 0.98 1.01
TM8Y100C16MP11 CF/CM64D 1.00 1.04 1.02
TM8Y100C20MP11 CF/CM/CU48C 0.94 0.94 1.00
TM8Y100C20MP11 CF/CM/CU48D 0.95 0.95 0.99
TM8Y100C20MP11 CF/CM/CU60C 0.97 0.97 0.99
TM8Y100C20MP11 CF/CM/CU60D 0.98 0.99 1.00
TM8Y100C20MP11 CF/CM64D 0.99 0.99 0.98
TM8Y120C20MP11 CF/CM/CU48C 0.94 0.94 1.00
TM8Y120C20MP11 CF/CM/CU48D 0.95 0.95 0.99
TM8Y120C20MP11 CF/CM/CU60C 0.97 0.97 0.99
TM8Y120C20MP11 CF/CM/CU60D 0.98 0.99 1.00
TM8Y120C20MP11 CF/CM64D 0.99 0.99 0.98
TM9E100C20MP11 CF/CM/CU48C 0.96 1.00 1.00
TM9E100C20MP11 CF/CM/CU48D 0.94 0.94 1.00
TM9E100C20MP11 CF/CM/CU60C 0.98 1.02 1.02
TM9E100C20MP11 CF/CM/CU60D 0.96 1.03 1.06
TM9E100C20MP11 CF/CM64D 1.00 1.04 1.02
TM9E120D20MP11 CF/CM/CU48D 0.95 0.96 1.01
TM9E120D20MP11 CF/CM/CU60D 0.99 1.05 1.03
TM9E120D20MP11 CF/CM64D 0.98 0.98 1.00
TM9V080C16MP12C CF/CM/CU48C 0.96 0.95 1.00
TM9V080C16MP12C CF/CM/CU48D 0.96 0.95 1.00
TM9V080C16MP12C CF/CM/CU60C 0.98 1.02 1.02
TM9V080C16MP12C CF/CM/CU60D 0.99 1.05 1.03
TM9V080C16MP12C CF/CM64D 0.98 0.98 1.00
TM9V100C16MP12C CF/CM/CU48C 0.96 0.98 1.00
TM9V100C16MP12C CF/CM/CU48D 0.96 0.98 0.98
TM9V100C16MP12C CF/CM/CU60C 0.98 1.01 1.00
TM9V100C16MP12C CF/CM/CU60D 0.99 1.05 1.01
TM9V100C16MP12C CF/CM64D 0.99 1.00 1.01
TM9V100C20MP12C CF/CM/CU60C 0.98 1.01 1.00
TM9V100C20MP12C CF/CM64D 1.01 1.07 1.02
TM9V120D20MP12C CF/CM/CU48D 0.96 0.98 0.98
TM9V120D20MP12C CF/CM/CU60D 0.98 0.99 0.97
TM9V120D20MP12C CF/CM64D 1.01 1.06 1.02
TM9Y100C20MP11 CF/CM/CU48C 0.96 1.00 1.00
TM9Y100C20MP11 CF/CM/CU48D 0.94 0.94 1.00
TM9Y100C20MP11 CF/CM/CU60C 0.98 1.02 1.02
TM9Y100C20MP11 CF/CM/CU60D 0.96 1.03 1.06
TM9Y100C20MP11 CF/CM64D 1.00 1.04 1.02
TM9Y120D20MP11 CF/CM/CU48D 0.95 0.96 1.01
TM9Y120D20MP11 CF/CM/CU60D 0.99 1.05 1.03
TM9Y120D20MP11 CF/CM64D 0.98 0.98 1.00
TMLV080C16MP12C CF/CM/CU48C 0.96 0.98 1.00
TMLV080C16MP12C CF/CM/CU48D 0.96 0.98 0.98
TMLV080C16MP12C CF/CM/CU60C 0.97 0.99 0.99
TMLV080C16MP12C CF/CM/CU60D 0.97 0.99 0.99
TMLV100C16MP12C CF/CM/CU48C 0.96 0.98 1.00
TMLV100C16MP12C CF/CM/CU48D 0.96 0.98 0.98
TMLV100C16MP12C CF/CM/CU60C 0.97 0.99 0.99
TMLV100C16MP12C CF/CM/CU60D 0.97 0.99 0.99
TMLV100C20MP12C CF/CM/CU48C 0.96 0.95 0.97
TMLV100C20MP12C CF/CM/CU48D 0.96 0.98 0.98
TMLV100C20MP12C CF/CM/CU60C 0.97 0.97 0.99
TMLV100C20MP12C CF/CM/CU60D 0.97 0.99 0.99
TMLV100C20MP12C CF/CM64D 0.99 1.01 0.98
TMLV120C20MP12C CF/CM/CU48C 0.96 0.95 0.97
FURNACE MULTIPLIERS - 5 TON (Continued)
Furnaces Coil T.C. S.C. KW
