Coleman CH16B6021S - Page 75

5547666-CTG-A-0718
Johnson Controls Unitary Products 75
CH16B4821S TPLC080B12MP13C 17.5 CF/CM48C
High 1200 45.5 32.0 15.75 9.25 48.0 28.2 9.00 7.05 3.02 2.42
Med 800 32.0 22.4 – 14.75 – – – – – –
Low 800 27.2 20.6 – 26.20 22.4 – – – 4.06 –
CH16B4821S TPLC080B12MP13C 17.5 CF/CM60C
High 1200 46.0 32.2 15.75 9.25 48.0 28.4 9.25 7.25 3.06 2.48
Med 800 32.0 22.4 – 14.85 ––––––
Low 800 26.8 20.2 – 26.05 22.0 – – – 4.04 –
CH16B4821S TPLC080B12MP13C 17.5 CF48CBCA1
High 1200 45.5 32.0 15.75 9.25 48.0 28.2 9.00 7.05 3.02 2.42
Med 800 32.0 22.4 – 14.75 – – – – – –
Low 800 27.2 20.6 – 26.20 22.4 – – – 4.06 –
CH16B4821S TPLC080C16MP13C 21.0 CF/CM48C
High 1275 46.0 33.2 16.25 9.75 48.0 28.0 9.25 7.10 3.14 2.52
Med 850 32.4 23.2 – 15.20 ––––––
Low 850 27.4 21.0 – 27.35 22.4 – – – 4.18 –
CH16B4821S TPLC080C16MP13C 21.0 CF/CM48D
High 1275 46.5 33.4 16.25 9.75 48.0 28.0 9.25 7.10 3.14 2.52
Med 850 32.4 23.2 – 15.20 – – – – – –
Low 850 27.4 21.0 – 27.40 22.4 – – – 4.20 –
CH16B4821S TPLC080C16MP13C 21.0 CF/CM60C
High 1275 47.0 33.6 16.00 9.75 47.5 28.2 9.25 7.30 3.16 2.56
Med 850 32.4 23.2 – 15.25 ––––––
Low 850 27.2 21.2 – 27.15 22.0 – – – 4.16 –
CH16B4821S TPLC080C16MP13C 21.0 CF/CM60D
High 1275 47.0 33.6 16.25 9.75 47.5 28.2 9.25 7.35 3.18 2.58
Med 850 32.4 23.2 – 15.30 – – – – – –
Low 850 27.2 21.2 – 27.30 22.0 – – – 4.18 –
CH16B4821S TPLC080C16MP13C 21.0 CF/CM64D
High 1275 47.5 34.0 16.00 10.00 46.5 29.0 9.50 7.70 3.30 2.70
Med 850 32.6 23.4 – 15.40 ––––––
Low 850 27.0 21.2 – 27.15 21.0 – – – 4.16 –
CH16B4821S TPLC080C16MP13C 21.0 CF48CBCA1
High 1275 46.0 33.2 16.25 9.75 48.0 28.0 9.25 7.10 3.14 2.52
Med 850 32.4 23.2 – 15.20 – – – – – –
Low 850 27.4 21.0 – 27.35 22.4 – – – 4.18 –
CH16B4821S TPLC100C16MP13C 21.0 CF/CM48C
High 1275 46.0 33.2 16.25 9.75 48.0 28.0 9.25 7.10 3.14 2.52
Med 850 32.4 23.2 – 15.20 ––––––
Low 850 27.4 21.0 – 27.35 22.4 – – – 4.18 –
CH16B4821S TPLC100C16MP13C 21.0 CF/CM48D
High 1275 46.5 33.4 16.25 9.75 48.0 28.0 9.25 7.10 3.14 2.52
Med 850 32.4 23.2 – 15.20 – – – – – –
Low 850 27.4 21.0 – 27.40 22.4 – – – 4.20 –
CH16B4821S TPLC100C16MP13C 21.0 CF/CM60C
High 1275 47.0 33.6 16.00 9.75 47.5 28.2 9.25 7.30 3.16 2.56
Med 850 32.4 23.2 – 15.25 ––––––
Low 850 27.2 21.2 – 27.15 22.0 – – – 4.16 –
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
Stage
COOLING HEATING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF IV HSPF V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
