Coleman CH16B6021S - Page 93

5547666-CTG-A-0718
Johnson Controls Unitary Products 93
CH16B6021S TP9C100C16MP13C 21.0 CF/CM60D
High 1600 55.5 41.0 15.50 9.75 60.0 33.6 8.75 6.65 2.98 2.38
Med 1100 37.2 28.4 – 14.50 – – – – – –
Low 1100 31.0 25.4 – 25.35 26.2 – – – 3.88 –
CH16B6021S TP9C100C16MP13C 21.0 CF/CM64D
High 1425 55.5 39.0 15.50 9.75 58.5 32.6 9.25 7.30 3.34 2.68
Med 975 37.0 26.8 – 14.65 ––––––
Low 975 30.6 24.2 – 25.85 25.2 – – – 4.08 –
CH16B6021S TP9C100C20MP13C 21.0 CF/CM60C
High 1475 55.0 39.0 15.50 9.75 60.0 33.6 8.75 6.75 2.94 2.34
Med 875 36.0 25.4 – 14.40 – – – – – –
Low 875 30.2 22.8 – 25.75 26.0 – – – 3.82 –
CH16B6021S TP9C100C20MP13C 21.0 CF/CM64D
High 1600 56.5 41.5 15.25 9.75 59.0 33.0 9.25 7.25 3.40 2.66
Med 975 37.0 27.0 – 14.60 ––––––
Low 975 30.6 24.0 – 25.65 25.2 – – – 4.08 –
CH16B6021S TP9C120D20MP13C 24.5 CF/CM48D
High 1425 54.0 38.0 15.75 9.75 60.0 33.6 8.50 6.35 2.78 2.24
Med 925 36.4 25.8 – 14.55 – – – – – –
Low 925 30.4 23.2 – 26.20 26.2 – – – 3.84 –
CH16B6021S TP9C120D20MP13C 24.5 CF/CM60D
High 1400 55.0 38.5 15.75 10.00 60.0 33.2 8.75 6.90 2.76 2.30
Med 900 36.4 25.8 – 14.55 ––––––
Low 900 30.4 23.4 – 26.20 26.2 – – – 3.80 –
CH16B6021S TP9C120D20MP13C 24.5 CF/CM64D
High 1575 56.5 41.0 15.75 9.75 58.5 32.6 9.25 7.20 3.44 2.70
Med 1000 37.0 27.4 – 14.70 – – – – – –
Low 1000 30.8 24.6 – 26.15 25.2 – – – 4.12 –
CH16B6021S TPLC080C16MP13C 21.0 CF/CM48C
High 1425 54.0 38.0 15.50 9.50 60.0 33.6 8.50 6.40 2.78 2.24
Med 900 35.4 24.8 – 14.40 ––––––
Low 900 30.2 22.8 – 25.70 26.4 – – – 3.78 –
CH16B6021S TPLC080C16MP13C 21.0 CF/CM48D
High 1425 54.0 38.0 15.50 9.75 60.0 33.6 8.50 6.40 2.78 2.24
Med 900 35.4 24.8 – 14.40 – – – – – –
Low 900 30.2 22.8 – 25.75 26.4 – – – 3.80 –
CH16B6021S TPLC080C16MP13C 21.0 CF/CM60C
High 1425 54.5 38.5 15.50 9.75 60.0 33.6 8.50 6.35 2.80 2.26
Med 900 35.6 25.4 – 14.35 ––––––
Low 900 30.2 23.2 – 25.60 26.4 – – – 3.78 –
CH16B6021S TPLC080C16MP13C 21.0 CF/CM60D
High 1425 54.5 38.5 15.50 9.75 60.0 33.4 8.75 6.80 2.80 2.28
Med 975 35.8 26.2 – 14.40 – – – – – –
Low 975 30.6 24.2 – 25.65 26.4 – – – 3.84 –
CH16B6021S TPLC100C16MP13C 21.0 CF/CM48C
High 1425 54.0 38.0 15.50 9.50 60.0 33.6 8.50 6.40 2.78 2.24
Med 900 35.4 24.8 – 14.40 ––––––
Low 900 30.2 22.8 – 25.70 26.4 – – – 3.78 –
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
Stage
COOLING HEATING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF IV HSPF V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
