TOOLS NEEDED FOR ASSEMBLY
• #2 Phillips screwdriver (long and short)
• Pliers
For correct hardware assembly, always
position the lock washer between the screw
and the flat washer.
HARDWARE PACK
NO.10-24UNC X10 Screw
X 22
NO.10-24UNC X13 Screw
X 3
Fiber Washer
X 14
ST4.2X6 Tapping Screw
X 1
Spacer
X 4
Hitch Pin
X 2
M10 Nut
X 1
Screw for Vent
X 2
Compression Spring
X 2
1/4’’-20UNC Wing Nut
X 2
1
9
2
3
4 5
6
7
10
8
No. Description Part Number Qty.
1 NO.10-24UNC X10 Screw 20124-10010-250 22
2 ST4.2X6 Tapping Screw 24200-42006-136 1
3 Screw for Vent G531-0048-9081 2
4 Fiber Washer G431-0018-9000 14
5 Spacer C305-0003-9000 4
6 Compression Spring G528-0058-9000 2
7 Hitch Pin G515-0013-9000 2
8 1/4’’-20UNC Wing Nut 33300-13000-032 2
9 NO.10-24UNC X13 Screw 20124-10013-250 3
10 M10 Nut 33401-10000-037 1
Lock Washer
Flat Washer
Screw
BEFORE ASSEMBLING THE COOKOUT™, READ THESE INSTRUCTIONS CAREFULLY.
Assemble the barbecue on a flat, clean surface.
Caution:
Sheet metal can cause injury. Wear gloves when installing the grill.
